Intel Core i5-14600KF 5.3GHz 6P+8E S1700 Processor

Home :: CPU/Processors :: Intel Desktop CPUs ::


Regularly: $442.00
On Sale: $380.96    Sale Ends: May 26th, 2024

Manufacturer: Intel

Boxed Intel® Core™ i5 processor 14600KF (24M Cache, up to 5.30 GHz) FC-LGA16A

Availability
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
Product # Manufacturer # UPC # Status
59443394 BX8071514600KF 5032037278461 Active

Details

Processor
Processor family Intel® Core™ i5
Processor cores 14
Processor socket LGA 1700
Box Yes
Cooler included No
Processor manufacturer Intel
Processor model i5-14600KF
Processor operating modes 64-bit
Processor generation Intel Core i5-14xxx
Processor threads 20
Performance cores 6
Efficient cores 8
Processor boost frequency 5.3 GHz
Performance-core boost frequency 5.3 GHz
Performance-core base frequency 3.5 GHz
Efficient-core boost frequency 4 GHz
Efficient-core base frequency 2.6 GHz
Processor cache 24 MB
Processor cache type Smart Cache
Processor base power 125 W
Maximum turbo power 181 W
Stepping B0
Maximum number of DMI lanes 8
Memory bandwidth supported by processor (max) 89.6 GB/s
Processor codename Raptor Lake
Processor ARK ID 236778
Memory
Memory channels Dual-channel
Maximum internal memory supported by processor 192 GB
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
Non-ECC Yes
Memory bandwidth (max) 89.6 GB/s
Graphics
On-board graphics card No
Discrete graphics card No
On-board graphics card model Not available
Discrete graphics card model Not available
Features
Execute Disable Bit Yes
Idle States Yes
Thermal Monitoring Technologies Yes
Market segment Desktop
Use conditions PC/Client/Tablet
Maximum number of PCI Express lanes 20
PCI Express slots version 4.0, 5.0
PCI Express configurations 1x16+1x4, 2x8+1x4
Supported instruction sets AVX 2.0, SSE4.1, SSE4.2
Scalability 1S
CPU configuration (max) 1
Embedded options available No
Thermal solution specification PCG 2020A
Direct Media Interface (DMI) Revision 4.0
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® Turbo Boost Technology 2.0
Intel® AES New Instructions (Intel® AES-NI) Yes
Enhanced Intel SpeedStep Technology Yes
Intel® Speed Shift Technology Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Intel® Control-flow Enforcement Technology (CET) Yes
Intel® Thread Director Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel® Secure Key Yes
Intel® OS Guard Yes
Intel 64 Yes
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel® Boot Guard Yes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Volume Management Device (VMD) Yes
Mode-based Execute Control (MBE) Yes
Intel® Standard Manageability (ISM) Yes
Operational conditions
Tjunction 100 °C
Logistics data
Harmonized System (HS) code 8542310001
Weight & dimensions
Processor package size 45 x 37.5 mm
Other features
L2 cache 20480 KB
Maximum internal memory 192 GB
Technical details
Launch date Q4'23
Status Launched
