Processor |
|
Processor family |
Intel® Core™ i9 |
|
Processor cores |
24 |
|
Processor socket |
LGA 1700 |
|
Box |
Yes |
|
Cooler included |
No |
|
Processor manufacturer |
Intel |
|
Processor model |
i9-14900KF |
|
Processor operating modes |
64-bit |
|
Processor generation |
Intel Core i9-14xxx |
|
Processor threads |
32 |
|
Performance cores |
8 |
|
Efficient cores |
16 |
|
Processor boost frequency |
6 GHz |
|
Performance-core boost frequency |
5.6 GHz |
|
Performance-core base frequency |
3.2 GHz |
|
Efficient-core boost frequency |
4.4 GHz |
|
Efficient-core base frequency |
2.4 GHz |
|
Processor cache |
36 MB |
|
Processor cache type |
Smart Cache |
|
Processor base power |
125 W |
|
Maximum turbo power |
253 W |
|
Stepping |
B0 |
|
Maximum number of DMI lanes |
8 |
|
Memory bandwidth supported by processor (max) |
89.6 GB/s |
|
Processor codename |
Raptor Lake |
|
Processor ARK ID |
236787 |
|
Memory |
|
Memory channels |
Dual-channel |
|
Maximum internal memory supported by processor |
192 GB |
|
Memory types supported by processor |
DDR4-SDRAM, DDR5-SDRAM |
|
Non-ECC |
Yes |
|
Memory bandwidth (max) |
89.6 GB/s |
|
Graphics |
|
On-board graphics card |
No |
|
Discrete graphics card |
No |
|
On-board graphics card model |
Not available |
|
Discrete graphics card model |
Not available |
|
Features |
|
Execute Disable Bit |
Yes |
|
Idle States |
Yes |
|
Thermal Monitoring Technologies |
Yes |
|
Market segment |
Desktop |
|
Use conditions |
PC/Client/Tablet |
|
Maximum number of PCI Express lanes |
20 |
|
PCI Express slots version |
4.0, 5.0 |
|
PCI Express configurations |
1x16+1x4, 2x8+1x4 |
|
Supported instruction sets |
AVX 2.0, SSE4.1, SSE4.2 |
|
Scalability |
1S |
|
CPU configuration (max) |
1 |
|
Embedded options available |
No |
|
Thermal solution specification |
PCG 2020A |
|
Direct Media Interface (DMI) Revision |
4.0 |
|
Export Control Classification Number (ECCN) |
5A992C |
|
Commodity Classification Automated Tracking System (CCATS) |
740.17B1 |
|
Processor special features |
|
Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
|
Intel® Turbo Boost Technology |
2.0 |
|
Intel® AES New Instructions (Intel® AES-NI) |
Yes |
|
Enhanced Intel SpeedStep Technology |
Yes |
|
Intel® Speed Shift Technology |
Yes |
|
Intel® Thermal Velocity Boost |
Yes |
|
Intel® Adaptive Boost Technology |
Yes |
|
Intel® Turbo Boost Max Technology 3.0 frequency |
5.8 GHz |
|
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 |
Yes |
|
Intel® Thermal Velocity Boost Frequency |
6 GHz |
|
Intel® Control-flow Enforcement Technology (CET) |
Yes |
|
Intel® Thread Director |
Yes |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel® Secure Key |
Yes |
|
Intel® OS Guard |
Yes |
|
Intel 64 |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
|
Intel Turbo Boost Max Technology 3.0 |
Yes |
|
Intel® Boot Guard |
Yes |
|
Intel® Deep Learning Boost (Intel® DL Boost) |
Yes |
|
Intel® Volume Management Device (VMD) |
Yes |
|
Mode-based Execute Control (MBE) |
Yes |
|
Intel® Standard Manageability (ISM) |
Yes |
|
Operational conditions |
|
Tjunction |
100 °C |
|
Logistics data |
|
Harmonized System (HS) code |
8542310001 |
|
Weight & dimensions |
|
Processor package size |
45 x 37.5 mm |
|
Other features |
|
L2 cache |
32768 KB |
|
Maximum internal memory |
192 GB |
|
Technical details |
|
Launch date |
Q4'23 |
|
Status |
Launched |
