D-Link DMS-3130-30TS 30-port Managed Gigabit Switch With 2x10g And 4x25g
|
|
Price: $3129.00
Manufacturer:
D-Link
Layer 3 Stackable Multi-Gigabit Managed Switches, UK
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
59480196
|
DMS-3130-30TS
|
790069467387 |
Active
|
Details
|
General Information |
|
Summary |
Accelerate your network with Multi-Gigabit Ethernet.
With two 10GBASE-T ports and four 10G/25G SFP28 ports, up to 400Gbps switching capacity, physical stacking of up to 9 switches for greater port density, and Layer 2 and Layer 3 features, the DMS-3130 Switch Series offer a versatile, secure, and fast network that can be deployed in a variety of environments and topologies, including Metro Ethernet deployments.
World-class reliability.
Advanced L2 and L3 features including port security, Storm Control, Link Aggregation, and Spanning Tree Protocols. Management options like 802.3ah OAM, 802.1ag CFM, and industry standard CLI support, with support for multiple images and multiple configurations.
x4 25G SFP28 uplink ports, physical stacking for redundancy, and have built-in G.8032 Ethernet Ring Protection Switching (ERPS) to help minimise recovery times to 50 ms. An USB 2.0 interface to store config files, boot images, and syslog. As well as support for an additional external redundant power supply on all models to ensure maximum uptime. DMS-3130-30PS even supports PoE PD function on the MGMT port, allowing it to be powered by a PoE switch.
Comprehensive security.
Includes the latest security such as Multi-layer and Packet Content Access Control Lists (ACL), and Storm Control. And our exclusive D-Link Safeguard Engine has been designed to guard against traffic flooding caused by malicious attacks and protect your business network uptime.
IP-MAC-Port Binding allows you to bind a source IP address with an associated MAC and define the port number to enhance user access control. And DHCP Snooping makes the switch learn IP/MAC pairs by snooping DHCP packets and saving them to the IMPB whitelist, giving you extra control.
Electrical surge protection.
Featuring built-in 6 kV surge protection on all PoE and non-PoE 2.5G/5G Ethernet access ports, the switches are protected against sudden electrical surges caused by lightning strikes or unstable electrical currents. It lowers maintenance costs effectively by minimising the need for expensive equipment repairs or replacements.
Easy Access Control policies.
They feature multiple authentication mechanisms such as 802.1X, Web-based Access Control (WAC), and MAC-based Access Control (MAC) for strict access control and an easy deployment. After authentication, individual policies such as VLAN membership, Quality of Service (QoS) policies, and ACL rules can be assigned to each host.
A stack above the competition.
Unlock the full potential of your network infrastructure. Utilise the high switching capacity of up to 400Gbps to eliminate bottlenecks and maintain optimal network efficiency even during peak times, enabling you to effortlessly handle demanding network environments.
Versatile traffic management.
The DMS-3130 Series has a rich set of multi-layer QoS/CoS features to ensure that critical network services such as VoIP, video conferences, IPTV, and IP surveillance are always given high priority. L2/L3 Multicast support enables your network to handle growing IPTV applications.
PoE+ /PoE++ with budgets up to 960W
PoE+ /PoE++ with budgets up to 960W DMS-3130-30PS provides sixteen 2.5G ports supporting 802.3af/at PoE and eight 5G ports supporting 60W 802.3bt PoE standards with a power budget of 740 watts expandable to 960 watts with dual power supplies.
Multi-Gigabit PoE with up to 60W of power per port is ideal for Wi-Fi 6/6E access points, smart lighting, or industrial automation equipment. Perpetual PoE and Fast PoE support delivers faster and uninterrupted power to connected devices even when the switch is booting.
|
|
Management features |
|
Switch type |
Managed |
|
Switch layer |
L3 |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
System event log |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
2 |
|
Basic switching RJ-45 Ethernet ports type |
10G Ethernet (100/1000/10000) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
10G Ethernet (copper) ports quantity |
2 |
|
SFP module slots quantity |
24 |
|
Console port |
RJ-45 |
|
USB 2.0 ports quantity |
1 |
|
Power connector |
AC-in jack |
|
Network |
|
Networking standards |
IEEE 802.11ad, IEEE 802.1ag, IEEE 802.3ah, IEEE 802.1p, IEEE 802.11d, IEEE 802.1s, IEEE 802.1AX, IEEE 802.3x, IEEE 802.1v, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x |
|
10G support |
Yes |
|
Port mirroring |
Yes |
|
Flow control support |
Yes |
|
Link aggregation |
Yes |
|
Broadcast storm control |
Yes |
|
Spanning tree protocol |
Yes |
|
Ethernet Ring Protection Switching (ERPS) |
Yes |
|
Fast leave |
Yes |
|
VLAN support |
Yes |
|
Virtual LAN features |
Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, Voice VLAN, Multicast VLAN, Private VLAN |
|
Number of VLANs |
4000 |
|
Data transmission |
|
MAC address table |
32768 entries |
|
Switching capacity |
360 Gbit/s |
|
Forwarding rate |
268 Mpps |
|
Number of queues |
8 |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9000 |
|
Packet buffer memory |
4 MB |
|
Security |
|
DHCP features |
DHCP client, DHCP relay, DHCP server, DHCP snooping |
|
Access Control List (ACL) |
Yes |
|
Access Control List (ACL) egress |
512 |
|
Access Control List (ACL) ingress |
2048 |
|
IGMP snooping |
Yes |
|
IGMP entries |
1024 |
|
Static port security |
Yes |
|
SSH/SSL support |
Yes |
|
Loop protection |
Yes |
|
BPDU filtering/protection |
Yes |
|
Authentication |
Guest VLAN |
|
Root protection |
Yes |
|
DoS attack prevention |
Yes |
|
Authentication type |
RADIUS, TACACS+ |
|
Queue scheduling algorithms |
Weighted Round Robin (WRR), Weighted random early detection (WRED), Strict Priority Queue (SPQ) |
|
Packet filtering |
L3 |
|
Multicast features |
|
Multicast support |
Yes |
|
MLD entries |
64 |
|
Protocols |
|
GARP VLAN Registration Protocol (GVRP) |
Yes |
|
Routing protocols |
OSPFv2, RIPng, OSPFv3, RIP-1, RIP-2 |
|
Design |
|
Stackable |
Yes |
|
Product colour |
Black |
|
Number of fans |
3 fan(s) |
|
Safety |
CB, cUL, BSMI, CCC |
|
Performance |
|
Physical stacking (units) |
9 |
|
Virtual stacking (units) |
32 |
|
Noise level |
52.5 dB |
|
sFlow |
Yes |
|
Mean time between failures (MTBF) |
270340 h |
|
Power |
|
Power source |
AC |
|
Power supply included |
Yes |
|
Redundant power supply (RPS) support |
Yes |
|
AC input voltage |
100 - 240 V |
|
Power consumption (max) |
74.26 W |
|
Surge protection |
Yes |
|
Surge protection voltage |
6 kV |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
No |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
10 - 90% |
|
Storage relative humidity (H-H) |
5 - 90% |
|
Heat dissipation |
253.38 BTU/h |
|
Weight & dimensions |
|
Width |
440 mm |
|
Depth |
250 mm |
|
Height |
250 mm |
|
Weight |
3.63 kg |
|
Certificates |
|
Certification |
FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI, CCC |
|
