Fractal Design Lumen S28 RGB V2 Aspect 14 280mm CPU Liquid/Water Cooler
|
|
Price: $171.00
Manufacturer:
Fractal Design
Water cooling, 2x 140 mm fans, 500-1700 RPM, Aluminum Radiator, RGB
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
59504497
|
FD-W-L1-S2812
|
7340172705949 |
Active
|
Details
|
General Information |
|
Summary |
Customize your CPU water-cooling from subtle to stunning with Lumen’s six addressable LEDs that you can command via motherboard or controller. Compatible with most common Intel/AMD sockets, including LGA1700 and AM5 and RGB certified by industry standards, the Lumen offers high-end cooling performance and premium ARGB effects for new and seasoned builders alike.
The right way up
- The removable top can be turned at 90-degree intervals, making the logotype horizontal independent of the mounting orientation
- Low-permeability rubber tubes with braided nylon sleeves
From subtle to stunning
- Duality design provides both a stealthy and illuminated look, controlled from your motherboard RGB UI
- Six ARGB LEDs are yours to command via your motherboard or controller
Color-coordinate your cooling
Compatible with ASUS AURA, Gigabyte Fusion, MSI Mystic Light, ASRock Polychrome and Razer Chroma
Forget the thermal paste
- Thermal paste is pre-applied to ensure a proper and pain-free installation
- Articulating elbow fittings make tubes easier to route and reduces tension on the cold plate housing
Common denominators
- Compatible with LGA 1700 and AM5
- Supports the most common sockets for both Intel and AMD
Powerful aspects
Aspect fans for low turbulence and chaining support |
|
Performance |
|
Suitable location |
Processor |
|
Type |
All-in-one liquid cooler |
|
Fan diameter |
14 cm |
|
Supported processor sockets |
LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket AM5, Socket FM1, Socket FM2, Socket FM2+ |
|
Rotational speed (min) |
500 RPM |
|
Rotational speed (max) |
1700 RPM |
|
Noise level (low speed) |
10 dB |
|
Noise level (high speed) |
35.5 dB |
|
Minimum airflow (imperial) |
20 cfm |
|
Maximum airflow |
78 cfm |
|
Minimum air pressure |
0.3 mmH2O |
|
Maximum air pressure |
2.05 mmH2O |
|
Pulse-width modulation (PWM) support |
Yes |
|
Pump noise level |
22 dB |
|
Fan bearing technology |
Rifle bearing |
|
Pump bearing technology |
Ceramic bearing |
|
Quantity per pack |
1 pc(s) |
|
Pump motor speed |
4000 RPM |
|
Pump's mean time to failure (MTTF) |
50000 h |
|
Fan's mean time to failure (MTTF) |
90000 h |
|
Design |
|
Product colour |
Black |
|
Radiator material |
Aluminum |
|
Base plate material |
Copper |
|
Number of fans |
2 fan(s) |
|
Fins material |
Aluminium |
|
Illumination LED |
Yes |
|
Number of LEDs |
6 |
|
Illumination colour |
Multi |
|
Power |
|
Pump voltage |
12 V |
|
Pump current |
340 mA |
|
Fan voltage |
12 V |
|
Fan current |
0.24 A |
|
Weight & dimensions |
|
Radiator width |
14 cm |
|
Radiator depth |
31.3 cm |
|
Radiator height |
2.7 cm |
|
Tube length |
40 cm |
|
Package width |
171 mm |
|
Package depth |
369 mm |
|
Package height |
183 mm |
|
Package weight |
2 kg |
|
Packaging content |
|
Package type |
Box |
|
Mounting kit |
Yes |
|
