General Information |
Summary |
Fuse Protection In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Optimized Composite Heatpipe The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Two-Ball Bearing These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in our tests. The improvements to the fan blades means the solution is up to 10% quieter than the previous generation.
Tough Metal Backplate The all-aluminum backplate provides additional rigidity that guarantees nothing bends and dust stays out. It also helps cool your card by increasing heat dissipation. |
Processor |
Graphics processor family |
AMD |
Graphics processor |
Radeon RX 7600 XT |
Maximum resolution |
7680 x 4320 pixels |
CUDA |
No |
Parallel processing technology support |
Not supported |
Processor boost clock speed |
2810 MHz |
Stream processors |
2048 |
Maximum displays per videocard |
4 |
Infinity cache |
32 MB |
Ray accelerators |
32 |
Memory |
Discrete graphics card memory |
16 GB |
Graphics card memory type |
GDDR6 |
Memory bus |
128 bit |
Data transfer rate |
18 Gbit/s |
Ports & interfaces |
Interface type |
PCI Express x8 4.0 |
HDMI ports quantity |
2 |
DVI-D ports quantity |
0 |
DVI-I ports quantity |
0 |
DisplayPorts quantity |
2 |
DisplayPort version |
2.1 |
Performance |
TV tuner integrated |
No |
DirectX version |
12 Ultimate |
Dual Link DVI |
No |
Virtual Reality (VR) ready |
Yes |
AMD FreeSync |
Yes |
Design |
Cooling type |
Active |
Cooling technology |
Sapphire Dual-X |
Number of fans |
2 fan(s) |
Number of slots |
2.2 |
Product colour |
Black |
Power |
Minimum system power supply |
600 W |
Supplementary power connectors |
2x 8-pin |
Power consumption (max) |
192 W |
System requirements |
Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
Linux operating systems supported |
Yes |
Minimum RAM |
8192 MB |
Weight & dimensions |
Length |
250 mm |
Depth |
44.6 mm |
Height |
129.2 mm |
Packaging data |
Package type |
Box |
