Security Never Shuts Down
Every Angle All on One Screen
4K HDMI Video Output & 16MP Decoding Capacity
Sharp image definition up to 8MP (4K) ensures you capture every detail. 8-ch@2MP decoding capacity allows you to enjoy more-channels live view and playback at the same time.†
Dedicated 16 PoE+ Ports for Simplified IP Camera Deployment.
Designed to use a single Ethernet cable for both data and power transmission, this NVR offers flexible installation to fit in various surveillance scenarios for small businesses, such as groceries, warehouses, restaurants, and financial institutions.
Reviewing Footage is Faster than Ever
16-Channel Simultaneous Playback*
Replay the feed from up to 16 cameras at the same time, increase replay speed,
and find events in the video schedule to easily review footage.
More Compression. More Savings. More Quality.
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
No Need to Check Long Compatibility Lists
ONVIF Ensures Compatibility
Easily add IPCs from VIGI and other brands to establish a powerful and varied network thanks to barrier-free compatibility. △
Auto Initialize for Quick Configuration
Just click "Auto Initialize" to set up basic IPC and hard disk parameters, including initialization and recording plans, significantly reducing your configuration time.
Security for Every Hour and Every Day
27/4 Continuous Recording
With the storage capacity of up to 20TB, the NVR supports 24/7 continuous local recording. Customize record schedule or record type to save storage space and quickly search out target footage.
Two-Way Audio
With voice intercom support, scare off any potential thieves or intruders from wherever you are.
Remote Management
Take full control over your security anytime and anywhere on the VIGI app or client.
Live Views and Real-Time Alerts
Easily check your business security via 24/7 live views. Get notifications as soon as the cameras detect something abnormal.
Easy & Smart Playback
Quickly review and locate certain video clips by event, vehicle, person, time, and more. This will greatly improve event backtracking efficiency and reduce labor costs.
Customized Monitoring Patterns
Based on your monitoring needs, you can freely preset motion zones, adjust the rotation angle, set zoom in & out, customize patrol routes, control patrol routes, and more.
Four-Way Management
Flexibly manage your cameras via the web UI, NVR UI, VIGI app, and VIGI Security Manager for ease and convenience.
One system. Full security.
Run your business with peace of mind.
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound. |
|
Performance |
|
Video input channels |
16 channels |
|
Maximum resolution |
3840 x 2160 pixels |
|
Number of simultaneously playbacked channels |
16 channels |
|
Video recording modes |
720p, 1080p |
|
Supported resolutions |
HDMI Output Resolution: 1 Channel, Resolution: 1280x720/60Hz, 1280x1024/60Hz, 1440x900/60Hz, 1680x1050/60Hz, 1920x1080/60Hz, 3840x2160/30Hz
VGA Output Resolution: 1 Channel, Resolution: 1280x720/60Hz, 1280x1024/60Hz, 1440x900/60Hz, 1680x1050/60Hz, 1920x1080/60Hz |
|
Video motion detection |
Yes |
|
Audio formats supported |
G.711 A-law, G.711 μ-law, G.726 |
|
Video formats supported |
H.264, H.264+, H.265, H.265+ |
|
Playback modes |
Digital zoom, Fast play, Forward, Full screen, Pause, Play, Stop |
|
Playback controls |
Yes |
|
Maximum frame rate |
30 fps |
|
Input bandwidth |
80 Mbit/s |
|
Output bandwidth |
60 Mbit/s |
|
Recording modes |
Manual, Schedule |
|
Wireless LAN features |
|
Wi-Fi |
No |
|
Hard drive |
|
Number of HDDs installed |
0 |
|
HDD capacity |
0 GB |
|
Maximum storage capacity |
10 TB |
|
HDD interface |
SATA |
|
Number of HDDs supported |
2 |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Power over Ethernet (PoE) |
Yes |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Power over Ethernet (PoE) ports quantity |
16 |
|
HDMI ports quantity |
1 |
|
VGA (D-Sub) output ports |
1 |
|
USB 2.0 ports quantity |
2 |
|
eSATA ports quantity |
1 |
|
Internal SATA ports quantity |
2 |
|
eSATA |
Yes |
|
Line-in |
Yes |
|
Audio output |
1 |
|
DC-in jack |
Yes |
|
Networking standards |
IEEE 802.3af, IEEE 802.3at |
|
Supported network protocols |
UPnP (Plug and Play), NTP (Network Timing) |
|
Features |
|
Reset button |
Yes |
|
Product colour |
Black |
|
Certification |
CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI |
|
Power |
|
Power consumption (max) |
40 W |
|
Output current |
2.43 A |
|
Output voltage |
53.5 V |
|
Total Power over Ethernet (PoE) budget |
90 W |
|
Operational conditions |
|
Operating temperature (T-T) |
-10 - 55 °C |
|
Operating relative humidity (H-H) |
10 - 90% |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Weight & dimensions |
|
Width |
330 mm |
|
Depth |
285 mm |
|
Height |
45 mm |
|
Weight |
1.9 kg |
|
Package weight |
3.2 kg |
|
Packaging content |
|
Cables included |
AC |
|
AC adapter included |
Yes |
|
Quick installation guide |
Yes |
|
