General Information |
|
Summary |
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
Intel® Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices. |
|
Ports & interfaces |
|
Connectivity technology |
Wired |
|
Host interface |
PCI Express |
|
Interface |
Fiber |
|
Fiber ports quantity |
4 |
|
PCI Card form factor |
Half-height (low-profile) |
|
Network |
|
Maximum data transfer rate |
10000 Mbit/s |
|
Networking standards |
IEEE 802.1Q, IEEE 802.1as, IEEE 802.1p, IEEE 802.3, IEEE 802.3ad |
|
Ethernet interface type |
10 Gigabit Ethernet, Gigabit Ethernet |
|
Ethernet LAN data rates |
1000,10000 Mbit/s |
|
Cabling technology |
10GBase-T |
|
VLAN tagging |
Yes |
|
iSCSI support |
Yes |
|
LAN controller |
Intel® XL710-AM1 |
|
Design |
|
Internal |
Yes |
|
Product colour |
Black, Green |
|
System requirements |
|
Compatible operating systems |
intel.com/support/EthernetOS |
|
Linux operating systems supported |
Yes |
|
Server operating systems supported |
Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012 R2, Windows Server 2012 R2 x64 |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 55 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Storage relative humidity (H-H) |
0 - 90% |
|
Other features |
|
Data transfer rate |
8 GT/s |
|
Cable type |
SFP+ Direct Attached Twin Axial Cabling up to 10m |
|
Number of VLANs |
4096 |
|
Intel Virtual Machine Device Queues (VMDq) |
Yes |
|
PCI-SIG* SR-IOV Capable |
Yes |
|
On-chip QoS and Traffic Management |
Yes |
|
Intel Flexible Port Partitioning |
Yes |
|
Intelligent Offloads |
Yes |
|
iWARP/RDMA |
No |
|
Fiber Channel over Ethernet |
No |
|
Intel Ethernet Power Management |
Yes |
|
Intel Data Direct I/O Technology |
Yes |
|
Intel Virtualization Technology for Connectivity (VT-c) |
Yes |
|
Interface type |
PCIe v3.0 (8.0 GT/s) |
|
Product type |
13 |
|
Ethernet adapter ARK ID |
83965 |
|
Status |
Launched |
|
Product family |
Intel 10 Gigabit server adapter |
|
Product series |
Intel Converged X710 |
|
Product codename |
Fortville |
