StarTech 1-Port Gigabit PoE+ Injector
|
|
Price: $50.00
Manufacturer:
StarTech
StarTech.com 1-Port Gigabit PoE+ Injector, 10M/100M/1G Ethernet, PoE/PoE+ (802.3af/802.3at), 30W Power Budget, Wall Mountable
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
59760377
|
AF211C-POE-INJECTOR
|
65030905169 |
Active
|
Details
|
General Information |
|
Summary |
Supply power and data to a remote Powered Device (PD) with this PoE/PoE+ injector
This 1-port multi-speed PoE+ Injector serves as a Power Sourcing Equipment (PSE) device and enables Ethernet speeds of 10Mbps, 100Mbps, and 1Gbps. This TAA-compliant mid-span inline injector can transmit network data and power up to 328ft (100m) for remote Powered Devices (PD).
Versatile PoE Injector
Single port PoE injector supports the IEEE 802.3af and 802.3at PSE standards, and delivers up to 30W output (54V DC, 0.6A). This enables seamless data and power transmission over Cat5/5e/6/6a to remote Powered Devices (PD) such as IP cameras, access control devices, remote kiosks (POSs), wireless access points (APs), PoE lighting, and digital signage. A built-in LAN Transformer reduces EMI to maintain strong, reliable signal strength across different environments.
Streamlined Cable Management
All Ethernet cables can be routed from one side of the unit for efficient and organized cable management. The compact design (4x2.3x1.3-inch-100x58.4x33.4 mm) ensures straightforward integration into existing network infrastructure, saving space and time during installation.
The StarTech.com Advantage
|
|
Network |
|
Ethernet interface type |
Gigabit Ethernet |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Cabling technology |
10/100/1000 |
|
Power over Ethernet (PoE) |
Yes |
|
Networking standards |
IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u |
|
Auto MDI/MDI-X |
Yes |
|
Cable types supported |
Cat5, Cat5e, Cat6, Cat6a |
|
Web-based management |
No |
|
Chipset |
Monolithic Power Systems - MP3924 |
|
Features |
|
Product colour |
Black |
|
Wall mountable |
Yes |
|
Maximum operating distance |
100 m |
|
LED indicators |
Power |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9000 |
|
Auto-negotiation |
Yes |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
2 |
|
RJ-45 input ports |
1 |
|
RJ-45 output ports |
1 |
|
Power |
|
AC adapter input voltage |
100 - 240 V |
|
Input current |
2.5 A |
|
AC adapter output voltage |
54 V |
|
Output current |
3.3 A |
|
Total Power over Ethernet (PoE) budget |
30 W |
|
Power plug type |
Type M |
|
Certificates |
|
Compliance certificates |
RoHS, UL |
|
Operational conditions |
|
Operating temperature (T-T) |
-10 - 70 °F |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Weight & dimensions |
|
Width |
58 mm |
|
Depth |
100 mm |
|
Height |
33 mm |
|
Weight |
100 g |
|
Packaging content |
|
AC adapter included |
Yes |
|
Power cord included |
Yes |
|
Quick installation guide |
Yes |
|
Packaging data |
|
Package width |
210 mm |
|
Package depth |
124 mm |
|
Package height |
51 mm |
|
Package weight |
424.5 g |
|
Logistics data |
|
Master (outer) case width |
510 mm |
|
Master (outer) case length |
262 mm |
|
Master (outer) case height |
343 mm |
|
Products per master (outer) case |
40 pc(s) |
|
Sustainability |
|
Sustainability compliance |
Yes |
|
