Processor |
|
Built-in processor |
No |
|
Processor socket |
LGA 1718 |
|
Memory |
|
Number of DIMM slots |
4 |
|
Supported memory types |
DDR5-SDRAM |
|
Maximum internal memory |
48 GB |
|
Memory form factor |
288-pin DIMM |
|
Memory voltage |
1.1 V |
|
ECC |
Yes |
|
Non-ECC |
Yes |
|
Graphics |
|
On-board graphics card model |
Aspeed AST2600 |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet interface type |
10 Gigabit Ethernet |
|
LAN controller |
Broadcom BCM57416 |
|
Ports & interfaces |
|
USB 2.0 ports quantity |
2 |
|
Ethernet LAN (RJ-45) ports |
2 |
|
IPMI LAN (RJ-45) port |
Yes |
|
HDMI ports quantity |
1 |
|
VGA (D-Sub) ports quantity |
1 |
|
BIOS |
|
BIOS type |
UEFI AMI |
|
BIOS memory size |
256 Mbit |
|
ACPI version |
5.1 |
|
System Management BIOS (SMBIOS) version |
2.3 |
|
Plug and Play |
Yes |
|
Design |
|
Chassis type |
Rack (1U) |
|
Power |
|
Power supply |
1600 W |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 35 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
20 - 90% |
|
Weight & dimensions |
|
Width |
438 mm |
|
Depth |
650 mm |
|
Height |
43.5 mm |
