TP-Link Omada Pro 8-port Gigabit Smart Switch
|
|
Price: $370.00
Manufacturer:
TP-Link
8x 10/100/1000Mbps RJ45 Ports, 32 MB Flash, 256 MB RAM, 16 Gbps, 11.90 Mpps, 209 x 126 x 26 mm
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
59765457
|
S4500-8G
|
4895252505573 |
Active
|
Details
|
General Information |
|
Summary |
What This Product Does
S4500-8G is an enterprise-level switch equipped with eight RJ45 ports (10/100/1000 Mbps). High-performance static routing, enterprise-level QoS, advanced security features, a selection of Layer 2 management options, and integration into the Omada Pro SDN (Software-Defined Networking) make S4500-8G an excellent choice for the access layer of business networking.
Secure Networking
Security features include IP-MAC-Port Binding and VLAN Binding, Port Security, Storm Control, and DHCP Snooping to defend against a range of network threats. An integrated list of common DoS attacks is available, making it easier than ever to prevent them.
In addition, the Access Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets based on source and destination MAC address, IP address, TCP/UDP ports, or VLAN ID. Users' network access can be controlled via 802.1X authentication, which works with a RADIUS/Tacacs+ server to grant access only when valid user credentials are provided.
Advanced QoS
Leveraging IP, MAC, TCP, and UDP identifiers, our QoS feature ensures seamless voice and video transmission—even when bandwidth is in short supply.
Abundant L2 and L2+ Features
S4500-8G supports a complete lineup of L2 features, including 802.1Q VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol, and 802.3x Flow Control. Advanced IGMP Snooping ensures the switch intelligently forwards multicast streams to only the appropriate subscribers, cutting out unnecessary traffic, while IGMP throttling and filtering restrict each subscriber on a port level to prevent unauthorized multicast access. Static Routing, an L2+ feature, is a simple way of segmenting the network and internally routing traffic through the switch for improved efficiency.
IPv6 Support
IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, IPv6 ACL, DHCPv6 Snooping, IPv6 Interface, Path Maximum Transmission Unit (PMTU) Discovery, and IPv6 Neighbor Discovery guarantee that your network is ready for the Next Generation Network (NGN) without upgrading your hardware.
Omada Pro Integration
Integration into the Omada Pro system brings centralized cloud management and a series of management features such as Zero-Touch Provisioning (ZTP) and Intelligent Anomaly Detection.* Omada Pro's Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and routers, providing 100% centralized cloud management. Omada Pro creates a highly scalable network—all controlled from a single interface.
Apart from the ability to be centrally managed via Omada Pro controllers, S4500-8G simplifies management via an intuitive web-based Graphical User Interface (GUI) or an industry-standard Command Line Interface (CLI). For both management methods, traffic is protected through SSL or SSH encryption. SNMP (v1/v2c/v3) and RMON support enable the switch to be polled for valuable status information and to send traps for abnormal events. |
|
Management features |
|
Switch type |
Managed |
|
Switch layer |
L2/L2+ |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
Traffic classification |
Yes |
|
System event log |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
Power connector |
DC-in jack |
|
Network |
|
Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|
10G support |
No |
|
Copper ethernet cabling technology |
100BASE-T, 1000BASE-T, 1000BASE-TX |
|
Cable types supported |
Cat3, Cat4, Cat5, Cat5e |
|
Port mirroring |
Yes |
|
Flow control support |
Yes |
|
Link aggregation |
Yes |
|
Broadcast storm control |
Yes |
|
Rate limiting |
Yes |
|
Spanning tree protocol |
Yes |
|
Active link detection |
Yes |
|
Virtual LAN features |
MAC address-based VLAN, Protocol-based VLAN, Voice VLAN |
|
Number of VLANs |
4000 |
|
Data transmission |
|
MAC address table |
8000 entries |
|
Switching capacity |
16 Gbit/s |
|
Forwarding rate |
11.9 Mpps |
|
Store-and-forward |
Yes |
|
Number of queues |
8 |
|
Static route |
Yes |
|
Number of static routes |
32 |
|
Number of IP interfaces |
16 |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9000 |
|
Packet buffer memory |
4.1 MB |
|
Security |
|
DHCP features |
DHCP relay, DHCP server |
|
Access Control List (ACL) |
Yes |
|
IGMP snooping |
Yes |
|
MAC address filtering |
Yes |
|
SSH/SSL support |
Yes |
|
Loop protection |
Yes |
|
Password protection |
Yes |
|
Authentication type |
RADIUS |
|
Multicast features |
|
Multicast support |
Yes |
|
Design |
|
Rack mounting |
No |
|
Product colour |
Grey |
|
LED indicators |
Yes |
|
Performance |
|
Internal memory |
256 MB |
|
Flash memory |
32 MB |
|
Fanless |
Yes |
|
Power |
|
Power source |
AC/DC |
|
Power supply included |
Yes |
|
AC input voltage |
220 V |
|
AC input frequency |
50 Hz |
|
Input current |
1 A |
|
Input voltage |
12 V |
|
Power consumption (max) |
6.4 W |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
No |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
10 - 90% |
|
Storage relative humidity (H-H) |
5 - 90% |
|
Heat dissipation |
21.84 BTU/h |
|
Weight & dimensions |
|
Width |
209 mm |
|
Depth |
126 mm |
|
Height |
26 mm |
|
Packaging content |
|
Quick start guide |
Yes |
|
Certificates |
|
Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
|
Sustainability |
|
Sustainability compliance |
Yes |
|
