General Information |
|
Summary |
Navigate security with smart managed switches
The changing landscape of security systems demands effective remote management. Hikvision’s latest Smart Managed Switches facilitate precise remote deployment and configuration. These switches are cloud-managed and seamlessly integrate with the Hik-Partner Pro (HPP) app, providing an easy way to securely manage your network anytime, anywhere.
Now you can quickly deploy and maintain your system and troubleshoot issues without having to go to the site. Security system management is now more convenient than ever. |
|
Management features |
|
Switch type |
Managed |
|
Web-based management |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
17 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
Gigabit Ethernet (copper) ports quantity |
17 |
|
SFP module slots quantity |
1 |
|
Network |
|
Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1w, IEEE 802.3af, IEEE 802.3at |
|
10G support |
No |
|
Port mirroring |
Yes |
|
Link aggregation |
Yes |
|
VLAN support |
Yes |
|
Number of VLANs |
32 |
|
Data transmission |
|
MAC address table |
8000 entries |
|
Switching capacity |
56 Gbit/s |
|
Forwarding rate |
41.66 Mpps |
|
Packet buffer memory |
4.1 MB |
|
Security |
|
DHCP features |
DHCP client |
|
Loop protection |
Yes |
|
Design |
|
Rack mounting |
Yes |
|
Product colour |
Grey |
|
Housing material |
Metal |
|
Power |
|
Power source |
AC/PoE |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50/60 Hz |
|
Input current |
4 A |
|
Power consumption (max) |
250 W |
|
Surge protection |
Yes |
|
Surge protection voltage |
6 kV |
|
Power protection features |
Surge protection |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet (PoE) power per port |
30 W |
|
Total Power over Ethernet (PoE) budget |
230 W |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 45 °C |
|
Storage temperature (T-T) |
-40 - 85 °C |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Storage relative humidity (H-H) |
5 - 95% |
|
Weight & dimensions |
|
Width |
440 mm |
|
Depth |
220.8 mm |
|
Height |
44 mm |
|
Weight |
2.65 kg |
|
Packaging data |
|
Package width |
309 mm |
|
Package depth |
528 mm |
|
Package height |
89 mm |
|
Package weight |
3.5 kg |
|
Certificates |
|
Certification |
CB;CE-EMC;CE-LVD;CE-RoHS;IC-VoC;KC;RCM |
|
Logistics data |
|
Harmonized System (HS) code |
301802747 |
|
Sustainability |
|
Sustainability compliance |
Yes |
