General Information |
|
Summary |
8-PORT MULTIGIG 2.5G UM SWITCH |
|
Management features |
|
Switch type |
Unmanaged |
|
Quality of Service (QoS) support |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
|
Network |
|
Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x |
|
10G support |
No |
|
Full duplex |
Yes |
|
Half duplex |
Yes |
|
Auto MDI/MDI-X |
Yes |
|
Head-of-line (HOL) blocking |
Yes |
|
Ethernet LAN data rates |
100,1000,2500 Mbit/s |
|
Cable length detection |
Yes |
|
Data transmission |
|
MAC address table |
16000 entries |
|
Switching capacity |
40 Gbit/s |
|
Forwarding rate |
3.72 Mpps |
|
Latency (1 Gbps) |
4.9 µs |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
12288 |
|
Packet buffer memory |
1 MB |
|
Design |
|
Rack mounting |
No |
|
Stackable |
No |
|
Product colour |
Black |
|
Housing material |
Metal |
|
LED indicators |
Yes |
|
Wall mountable |
Yes |
|
Number of fans |
0 fan(s) |
|
Performance |
|
Noise level |
0 dB |
|
Fanless |
Yes |
|
Mean time between failures (MTBF) |
3309911 h |
|
Power |
|
Power source |
DC |
|
Power supply included |
Yes |
|
DC input voltage |
12 V |
|
Input current |
1 A |
|
Input voltage |
12 V |
|
Power consumption (max) |
7.98 W |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
No |
|
Other features |
|
Warranty period |
3 year(s) |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Weight & dimensions |
|
Width |
158 mm |
|
Depth |
101 mm |
|
Height |
27 mm |
|
Weight |
430 g |
|
Certificates |
|
Compliance certificates |
CCC, Low Voltage Directive (LVD) |
