POWERFUL CONNECTIONS
With three EPS12V connectors and fully modular cabling, HXi Series platinum power supplies have every connection needed to power today’s most demanding PC upgrades now and into the future, including the latest generation of power-hungry graphics cards and processors.
ATX 3.0 CERTIFIED
The ATX 3.0 standard demands a high level of reliability and power efficiency. While many CORSAIR PSUs meet these requirements, HXi Series PSUs are formally certified for ATX 3.0 compliance.
PCIe 5.0 12VHPWR GPU cable included for use with modern graphics cards such as the NVIDIA® GeForce RTX™ 40 Series.
QUIET OPERATION
HXi Series PSUs combine a 140mm fluid dynamic bearing fan with Zero RPM mode support for long-lasting fan performance and near-silent operation when the fan switches off at low and medium loads – only spinning as fast as it needs to.
UNWAVERING POWER AND QUALITY
80 PLUS Platinum certified with premium 100% Japanese 105°C electrolytic capacitors, HXi PSUs ensure up to 92% efficiency for exceptional power delivery and long-term reliability with low power consumption, less noise, and cooler temperatures. |
|
Power |
|
Total power |
1500 W |
|
AC input voltage |
200 - 240 V |
|
AC input frequency |
47 - 63 Hz |
|
Input current |
10 A |
|
Combined power (+3.3V) |
150 W |
|
Combined power (+12V) |
1500 W |
|
Combined power (+5V) |
150 W |
|
Combined power (+5Vsb) |
17.5 W |
|
Max output current (+3.3V) |
25 A |
|
Max output current (+12V) |
125 A |
|
Max output current (+5V) |
25 A |
|
Max output current (+5Vsb) |
3.5 A |
|
Ports & interfaces |
|
Motherboard power connector |
24-pin ATX |
|
Motherboard power cable length |
61 cm |
|
Number of SATA power connectors |
8 |
|
Number of PATA power connectors |
8 |
|
SATA power cable length |
800 mm |
|
EPS power connector (8-pin) |
No |
|
EPS power connector (4+4 pin) |
Yes |
|
PCI Express power connectors (6+2 pin) |
2 |
|
PCI Express power cable length |
65 cm |
|
Cabling type |
Fully-Modular |
|
Performance |
|
Purpose |
PC/Server |
|
Power supply unit (PSU) form factor |
ATX |
|
80 PLUS certification |
80 PLUS Platinum |
|
Supported motherboard form factors |
ATX |
|
ATX version |
3.0 |
|
Bearing technology |
FDB |
|
Mean time between failures (MTBF) |
100000 h |
|
Design |
|
Product colour |
Black |
|
Cooling type |
Active |
|
Fan diameter |
14 cm |
|
Number of fans |
1 fan(s) |
|
Fan location |
Top |
|
Illumination |
No |
|
On/off switch |
Yes |
