General Information |
|
Summary |
Real possibilities come from within
- Up to 12th Gen Intel® Core™ i3 mobile processing power
- Can be virtual or cloud-based PC, offering real versatility
- Low maintenance tiny desktop, can live almost anywhere
- Blazing-fast storage & memory, optional board-to-board port
- Secure from the inside out, plus easily scalable
- Space-saving, cost-effective, & energy-efficient
|
|
Processor |
|
Processor manufacturer |
Intel |
|
Processor family |
Intel® Celeron® |
|
Processor model |
7305 |
|
Processor cores |
5 |
|
Processor cache |
8 MB |
|
Motherboard chipset |
Intel SoC |
|
Processor base power |
15 W |
|
Maximum turbo power |
55 W |
|
Memory |
|
Internal memory |
16 GB |
|
Internal memory type |
DDR4-SDRAM |
|
Memory clock speed |
3200 MHz |
|
Memory slots |
1x SO-DIMM |
|
Memory layout (slots x size) |
1 x 16 GB |
|
Maximum internal memory |
16 GB |
|
Storage |
|
Total storage capacity |
256 GB |
|
Storage media |
SSD |
|
Number of storage drives installed |
1 |
|
Card reader integrated |
No |
|
SSD form factor |
M.2 |
|
NVMe |
Yes |
|
Graphics |
|
On-board graphics card |
Yes |
|
On-board graphics card model |
Intel® UHD Graphics |
|
Discrete graphics card model |
Not available |
|
Audio |
|
Built-in speaker(s) |
Yes |
|
Number of built-in speakers |
1 |
|
Speaker power |
2 W |
|
Audio system |
High Definition (HD) Audio |
|
Network |
|
Wi-Fi |
Yes |
|
Ethernet LAN |
Yes |
|
Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
|
Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
|
Ethernet LAN data rates |
100,1000 Mbit/s |
|
Cabling technology |
10/100/1000Base-T(X) |
|
Bluetooth |
Yes |
|
Bluetooth version |
5.1 |
|
WLAN controller model |
Intel Wi-Fi 6 AX201 |
|
WLAN controller manufacturer |
Intel |
|
Antenna type |
2x2 |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
1 |
|
USB 2.0 ports quantity |
2 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
|
Combo headphone/mic port |
Yes |
|
DisplayPorts quantity |
1 |
|
HDMI ports quantity |
1 |
|
Design |
|
Product colour |
Black |
|
VESA mounting |
No |
|
Cable lock slot |
Yes |
|
Cable lock slot type |
Kensington |
|
Display |
|
Display included |
No |
|
Software |
|
Operating system installed |
Windows 10 IoT Enterprise |
|
Operating system language |
English |
|
Trusted Platform Module (TPM) |
Yes |
|
Power |
|
Power supply |
65 W |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 35 °C |
|
Storage temperature (T-T) |
-40 - 60 °C |
|
Operating relative humidity (H-H) |
20 - 80% |
|
Storage relative humidity (H-H) |
10 - 90% |
|
Operating altitude |
-15.2 - 3048 m |
|
Non-operating altitude |
-15.2 - 10668 m |
|
Certificates |
|
Certification |
ErP Lot 3 and Lot 7
TCO Certified 9.0
RoHS compliant |
|
Sustainability |
|
Sustainability certificates |
ErP, TCO |
|
Weight & dimensions |
|
Width |
179 mm |
|
Depth |
182.9 mm |
|
Height |
36.5 mm |
|
Weight |
1.11 kg |
|
Packaging data |
|
Package width |
140 mm |
|
Package depth |
262 mm |
|
Package height |
500 mm |
|
Package weight |
5.18 kg |
|
Packaging content |
|
Mouse included |
Yes |
|
Keyboard included |
Yes |
|
Mouse connectivity |
Wired |
|
Keyboard connectivity |
Wired |
|
Technical details |
|
Compliance certificates |
RoHS |
|
Other features |
|
Chassis type |
Mini PC |
|
SSD interface |
PCI Express 4.0 |
