Camera |
|
Connectivity technology |
Wired |
|
Camera included |
Yes |
|
Colour |
Yes |
|
Surveillance camera form factor |
Turret |
|
Camera interface |
RJ-45 |
|
Placement supported |
Indoor/outdoor |
|
Rotating |
Yes |
|
Day/night mode |
Yes |
|
Infrared (IR) cut-off filter |
Yes |
|
Infra-red wavelength |
850 nm |
|
Camera maximum memory card size |
512 GB |
|
Camera compatible memory cards |
MicroSD (TransFlash) |
|
Fixed focal length |
2.8 mm |
|
Maximum aperture number |
1.6 |
|
Number of cameras |
1 |
|
Housing material |
Metal, Plastic |
|
Night vision distance |
30 m |
|
Number of illumination LEDs |
4 |
|
Sensor type |
CMOS |
|
Optical sensor size |
25.4 / 2.7 mm (1 / 2.7") |
|
Minimum illumination |
0.005 lx |
|
LED type |
IR/White |
|
Camera shutter speed |
1/3 - 1/10000 s |
|
Supported resolutions |
2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 |
|
Minimum aperture number |
1.6 |
|
Progressive scan |
Yes |
|
International Protection (IP) code |
IP67 |
|
Recorder |
|
Recorder included |
Yes |
|
Channels quantity |
4 channels |
|
Storage media type |
HDD |
|
Total storage capacity |
2 GB |
|
Maximum storage capacity |
10 TB |
|
Video recording modes |
720p, 1080p |
|
Frame rate |
30 fps |
|
VGA (D-Sub) ports quantity |
1 |
|
USB 2.0 ports quantity |
2 |
|
HDD interface |
SATA |
|
Supported network protocols |
UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
|
DC-in jack |
Yes |
|
HDMI ports quantity |
1 |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Total Power over Ethernet (PoE) budget |
53 W |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet interface type |
Fast Ethernet |
|
Power |
|
Power source type |
DC, PoE |
|
Power consumption (max) |
13.1 W |
|
Audio |
|
Built-in microphone |
Yes |
|
Built-in speaker(s) |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
-30 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 95% |
|
Storage temperature (T-T) |
-40 - 60 °C |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Technical details |
|
Video compression formats |
H.264, H.264+, H.265, H.265+ |
|
Product colour |
White, Black |
|
Reset button |
Yes |
|
Weight & dimensions |
|
Camera width |
11.1 cm |
|
Camera depth |
11.1 cm |
|
Camera height |
8.37 cm |
|
Camera weight |
480 g |
|
Recorder width |
24.6 cm |
|
Recorder depth |
14.8 cm |
|
Recorder height |
4.5 cm |
