General Information |
|
Summary |
TeraStation 3230DN 8TB 2 Bay Desktop NAS 2x4TB NAS HDD Included 2.5GBE RAID iSCSI |
|
Storage |
|
Storage drives installed |
Yes |
|
Total installed storage capacity |
8 TB |
|
Number of storage drives installed |
2 |
|
Number of storage drives supported |
2 |
|
Installed storage drive type |
HDD |
|
Supported storage drive types |
HDD & SSD |
|
Storage drive capacity |
4 TB |
|
Storage drive interface |
Serial ATA III |
|
RAID support |
Yes |
|
Supported storage drive interfaces |
Serial ATA III |
|
RAID levels |
0, 1, JBOD |
|
Hot-swap drive bays |
Yes |
|
Supported file systems |
BTRFS |
|
Processor |
|
Processor family |
Alpine |
|
Processor manufacturer |
Annapurna Labs |
|
Processor model |
AL524 |
|
Processor frequency |
2 GHz |
|
Processor cores |
4 |
|
Memory |
|
Internal memory |
2 GB |
|
Internal memory type |
DDR4 |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN data rates |
1000,2500 Mbit/s |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
2 |
|
USB port |
Yes |
|
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
|
Design |
|
Chassis type |
Desktop |
|
Product colour |
Black |
|
Performance |
|
Type |
NAS |
|
Device class |
Home & Home Office |
|
Backup function |
Yes |
|
Web-based management |
Yes |
|
On/off switch |
Yes |
|
Password authentication |
Yes |
|
Power |
|
Power consumption (max) |
85 W |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50/60 Hz |
|
Weight & dimensions |
|
Width |
170.1 mm |
|
Depth |
170.1 mm |
|
Height |
231.1 mm |
|
Weight |
4.31 kg |
|
Package width |
309.8 mm |
|
Package depth |
320 mm |
|
Package height |
358.1 mm |
|
Package weight |
5.72 kg |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
10 - 85 °C |
