General Information |
|
Summary |
5Port Industrial Gigabit PoE+ WallMounted Front Access Switch |
|
Management features |
|
Switch type |
Unmanaged |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
5 |
|
Network |
|
Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x |
|
Port mirroring |
Yes |
|
Data transmission |
|
MAC address table |
2000 entries |
|
Switching capacity |
10 Gbit/s |
|
Forwarding rate |
7.44 Mpps |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9000 |
|
Packet buffer memory |
64 MB |
|
Security |
|
MAC address filtering |
Yes |
|
Design |
|
Rack mounting |
No |
|
Stackable |
No |
|
Product colour |
Black |
|
Performance |
|
Mean time between failures (MTBF) |
454556 h |
|
Power |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50 - 60 Hz |
|
Input current |
2 A |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet plus (PoE+) ports quantity |
4 |
|
Total Power over Ethernet (PoE) budget |
200 W |
|
Operational conditions |
|
Operating temperature (T-T) |
-40 - 75 °C |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Weight & dimensions |
|
Width |
118 mm |
|
Depth |
23.5 mm |
|
Height |
118 mm |
|
Weight |
425 g |
|
Packaging content |
|
Quick start guide |
No |
|
Rack mount kit |
Yes |
|
Certificates |
|
Certification |
CE
FCC
UL
Shock (IEC 60068-2-27)
Freefall (IEC 60068-2-32)
Vibration (IEC 60068-2-6) |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
