General Information |
|
Summary |
Made for team collaboration, this monitor provides up to 90W power delivery via USB-C and flexibility to include an OptiPlex Micro based on your needs. |
|
Display |
|
Display diagonal |
138.8 cm (54.6") |
|
Display technology |
LCD |
|
Display resolution |
3840 x 2160 pixels |
|
Display brightness |
400 cd/m² |
|
HD type |
4K Ultra HD |
|
Touchscreen |
No |
|
Panel type |
IPS |
|
LED backlight |
Yes |
|
LED backlighting type |
Edge-LED |
|
Native aspect ratio |
16:9 |
|
Response time |
8 ms |
|
Contrast ratio (typical) |
1200:1 |
|
Viewing angle, horizontal |
178° |
|
Viewing angle, vertical |
178° |
|
Display number of colours |
1.07 billion colours |
|
Pixel pitch |
0.315 x 0.315 mm |
|
Active display area (W x H) |
1209.6 x 680.4 mm |
|
Display diagonal (metric) |
138.787 cm |
|
Horizontal scan range |
30 - 140 kHz |
|
Vertical scan range |
24 - 75 Hz |
|
Supported graphics resolutions |
640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1152, 2560 x 1440, 3840 x 2160 |
|
Supported video modes |
480p, 576p, 720p, 1080i, 1080p, 2160p |
|
Colour depth |
8 bit |
|
Haze rate |
25% |
|
Surface hardness |
3H |
|
Colour gamut |
72% |
|
Ports & interfaces |
|
HDMI ports quantity |
2 |
|
DVI port |
No |
|
DisplayPorts quantity |
2 |
|
USB port |
Yes |
|
Ethernet LAN |
Yes |
|
HDMI version |
2.0 |
|
DisplayPort version |
1.4 |
|
USB version |
3.2 Gen 1 (3.1 Gen 1) |
|
USB connector type |
USB Type-A, USB Type-B, USB Type-C |
|
USB 2.0 Type-B ports quantity |
1 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
2 |
|
USB Power Delivery (USB PD) |
Yes |
|
USB Power Delivery up to |
90 W |
|
USB Type-C DisplayPort Alternate Mode |
Yes |
|
Ethernet LAN (RJ-45) ports |
1 |
|
RS-232C |
Yes |
|
DC-in jack |
Yes |
|
Audio |
|
Built-in speaker(s) |
Yes |
|
Number of built-in speakers |
2 |
|
RMS rated power |
20 W |
|
Design |
|
Product design |
Digital signage flat panel |
|
Product colour |
Black |
|
Placement supported |
Indoor |
|
VESA mounting |
Yes |
|
Panel mounting interface |
300 x 400 mm |
|
Bezel width (bottom) |
2.85 cm |
|
Bezel width (side) |
1.89 cm |
|
Bezel width (top) |
1.89 cm |
|
Anti-glare screen |
Yes |
|
Performance |
|
Purpose |
Commercial |
|
Power |
|
Power consumption (typical) |
77.1 W |
|
Power consumption (standby) |
0.5 W |
|
Power consumption (off) |
0.3 W |
|
Power consumption (max) |
300 W |
|
Energy efficiency class (SDR) |
E |
|
Energy consumption (SDR) per 1000 hours |
77 kWh |
|
AC input voltage |
100-240 V |
|
AC input frequency |
50/60 Hz |
|
Weight & dimensions |
|
Width |
1247.4 mm |
|
Depth |
79.8 mm |
|
Height |
727.8 mm |
|
Weight |
22.4 kg |
|
Packaging data |
|
Package weight |
33.8 kg |
|
Packaging content |
|
Remote control included |
Yes |
|
Cables included |
AC, DisplayPort, HDMI, USB, USB Type-C |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Operating relative humidity (H-H) |
10 - 80% |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Storage relative humidity (H-H) |
5 - 90% |
|
Technical details |
|
Sustainability certificates |
ENERGY STAR, TCO |
|
Doesn't contain |
Arsenic, Mercury, PVC/BFR |
|
Compliance certificates |
RoHS |
|
Other features |
|
Quick start guide |
Yes |
|
Remote control battery |
AAA x 2 |
