Processor |
|
Processor family |
Intel Xeon Silver |
|
Processor cores |
16 |
|
Processor socket |
LGA 4677 (Socket E) |
|
Package type |
Box |
|
Processor manufacturer |
Intel |
|
Processor model |
4514Y |
|
Processor base frequency |
2 GHz |
|
Processor operating modes |
64-bit |
|
Processor generation |
Intel Xeon Scalable 5th Gen |
|
Processor threads |
32 |
|
Intel® UPI Speed |
16 GT/s |
|
Processor boost frequency |
3.4 GHz |
|
Processor cache |
30 MB |
|
Thermal Design Power (TDP) |
150 W |
|
Stepping |
R1 |
|
Processor ARK ID |
237557 |
|
Memory |
|
Memory channels |
Octa-channel |
|
Maximum internal memory supported by processor |
4 TB |
|
Memory types supported by processor |
DDR5-SDRAM |
|
ECC |
Yes |
|
Graphics |
|
On-board graphics card |
No |
|
Discrete graphics card |
No |
|
On-board graphics card model |
Not available |
|
Discrete graphics card model |
Not available |
|
Features |
|
Execute Disable Bit |
Yes |
|
Market segment |
Server |
|
Use conditions |
Server/Enterprise |
|
Maximum number of PCI Express lanes |
80 |
|
PCI Express slots version |
5.0 |
|
Supported instruction sets |
AMX, AVX, AVX 2.0, AVX-512, SSE4.2 |
|
Scalability |
2S |
|
Embedded options available |
Yes |
|
Export Control Classification Number (ECCN) |
5A992C |
|
Commodity Classification Automated Tracking System (CCATS) |
740.17B1 |
|
Processor special features |
|
Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
|
Intel® Turbo Boost Technology |
2.0 |
|
Intel® AES New Instructions (Intel® AES-NI) |
Yes |
|
Intel Trusted Execution Technology |
Yes |
|
Intel® Speed Shift Technology |
Yes |
|
Intel® Transactional Synchronization Extensions |
Yes |
|
Intel® Total Memory Encryption |
Yes |
|
Intel® Control-flow Enforcement Technology (CET) |
Yes |
|
Intel® Crypto Acceleration |
Yes |
|
Intel® Platform Firmware Resilience Support |
Yes |
|
Maximum Enclave Size Support for Intel® SGX |
64 GB |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel® OS Guard |
Yes |
|
Intel Software Guard Extensions (Intel SGX) |
Yes |
|
Intel 64 |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
|
AVX-512 Fused Multiply-Add (FMA) units |
2 |
|
Intel® Boot Guard |
Yes |
|
Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
|
Intel® Resource Director Technology (Intel® RDT) |
Yes |
|
Intel® Volume Management Device (VMD) |
Yes |
|
Mode-based Execute Control (MBE) |
Yes |
|
Intel® Total Memory Encryption - Multi Key |
Yes |
|
Intel® QuickAssist Software Acceleration |
Yes |
|
Intel® On Demand Feature Activation |
Yes |
|
Intel® Data Streaming Accelerator (DSA) |
1 default devices |
|
Intel® Advanced Matrix Extensions (AMX) |
Yes |
|
Intel® Speed Select Technology – Core Power |
Yes |
|
Operational conditions |
|
Tcase |
79 °C |
|
DTS Max |
90 °C |
|
Technical details |
|
Package carrier |
E1B |
|
Launch date |
Q4'23 |
|
Status |
Launched |
|
Number of UPI links |
2 |
|
Servicing status |
Baseline Servicing |
|
Logistics data |
|
Harmonized System (HS) code |
8542310001 |
|
Weight & dimensions |
|
Processor package size |
77.5 x 56.5 mm |
|
Other features |
|
Maximum internal memory |
4 TB |
