General Information |
|
Summary |
EnGenius Cloud Managed Wi-Fi 5 4x4 Indoor Access Point delivers supercharged speeds up to 1800 Mbps (5 GHz) & 800 Mbps (2.4 GHz), Wave 2 MU-MIMO, accommodating more clients, and improved connections. Featuring remote management, Gigabit Ethernet PoE port, quick-scan device registration, and EnGenius Cloud App for unlimited AP management. Mesh Wireless Support streamlines setup and optimizes signal quality.
|
|
Features |
|
2.4 GHz |
Yes |
|
5 GHz |
Yes |
|
6 GHz |
No |
|
Maximum data transfer rate |
1800 Mbit/s |
|
Maximum data transfer rate (2.4 GHz) |
800 Mbit/s |
|
Maximum data transfer rate (5 GHz) |
1800 Mbit/s |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at |
|
Cabling technology |
10/100/1000Base-T(X) |
|
MIMO |
Yes |
|
MIMO type |
Multi User MIMO |
|
Wi-Fi Multimedia (WMM)/(WME) |
Yes |
|
VLAN support |
Yes |
|
Security |
|
Security algorithms |
WPA2-Enterprise, WPA2-PSK, WPA3-Enterprise, WPA3-PSK |
|
Number of SSID supported |
8 |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
2 |
|
USB 2.0 ports quantity |
0 |
|
DC-in jack |
Yes |
|
Power |
|
Power over Ethernet (PoE) |
Yes |
|
Design |
|
Placement |
Ceiling, Wall |
|
Product colour |
White |
|
Reset button |
Yes |
|
LED indicators |
Yes |
|
Antenna |
|
Antenna type |
Internal |
|
Antenna direction type |
Omni-directional |
|
Performance |
|
Built-in processor |
Yes |
|
Processor frequency |
2200 MHz |
|
Weight & dimensions |
|
Width |
215 mm |
|
Depth |
215 mm |
|
Height |
56 mm |
|
Weight |
630 g |
|
Packaging data |
|
Package width |
253 mm |
|
Package depth |
249 mm |
|
Package height |
107 mm |
|
Package weight |
1.02 kg |
|
Packaging content |
|
Quantity per pack |
1 pc(s) |
|
Operational conditions |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-30 - 80 °C |
|
Storage relative humidity (H-H) |
0 - 90% |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
|
Master (outer) case width |
521 mm |
|
Master (outer) case length |
560 mm |
|
Master (outer) case height |
295 mm |
|
Master (outer) case gross weight |
11.4 kg |
|
Products per master (outer) case |
10 pc(s) |
