Axis S1224 12TB Rack Video Recorder Server
|
|
Price: $19142.00
Manufacturer:
Axis
Camera Station S1224 Rack Recording Server
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
59977822
|
03237-001
|
7331021091313 |
Active
|
Details
|
General Information |
|
Summary |
Featuring powerful components, in a 1U rack form factor this recording server offers support for powerful applications and features. This secure device complies with government policies and uses a Trusted Platform Module (TPM) that is FIPS 140-2 level 2, which increases the security of the product and ensures recorded video is stored encrypted on the hard drive. It comes with a built-in operating system recovery stored on the device, to make it easier to recover data if needed.
Flexible, scalable solution
AXIS S1224 Rack is ideal for demanding applications. With great scalability, it’s easy to expand your system as it grows without the need for additional hardware. It includes 24 AXIS Camera Station Pro licenses and provides 10 AXIS Audio Manager Pro licenses when installing the software to the server. You can expand your system up to a recording bitrate of 300 Mbit/s (approximately 32 channels) . AXIS S1224 Rack is available with 12 TB storage and can easily be expanded with one additional hard drive available as optional accessory, based on your specific requirements.
Quality and ease-of-use
This reliable recording server and client comes pre-loaded with AXIS Camera Station Pro licenses and all necessary software, so there’s no need to spend time selecting, configuring, and testing hardware. Plus, with services such as Keep Your Hard Drive and Next Business Day Onsite Support*, as well as a 5-year warranty, you can depend on Axis for first-class quality, reliability, and support. Part of an Axis end-to-end solution, all supported products are available in one price list for a one-stop-shop experience. Furthermore, with an intuitive installation wizard and AXIS Recorder Toolbox, AXIS S1224 help ensure every installation is trouble-free. |
|
Processor |
|
Processor manufacturer |
Intel |
|
Processor family |
Intel® Xeon® |
|
Memory |
|
Internal memory |
16 GB |
|
Memory layout (slots x size) |
1 x 16 GB |
|
Storage |
|
Number of HDDs supported |
2 |
|
HDD interface |
SATA |
|
Hot-swap drive bays |
No |
|
Total storage capacity |
12 TB |
|
RAID support |
Yes |
|
HDD capacity |
12 GB |
|
Number of HDDs installed |
1 |
|
RAID levels |
0, 1 |
|
Hot-swap |
No |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
2 |
|
USB 2.0 ports quantity |
2 |
|
Ethernet interface type |
Gigabit Ethernet |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
|
VGA (D-Sub) output ports |
1 |
|
Features |
|
Operating system installed |
Windows 11 IoT Enterprise LTSC 2024 |
|
Ethernet LAN data rates |
1000 Mbit/s |
|
Design |
|
Chassis type |
Rack |
|
Rack capacity |
1U |
|
LED indicators |
Yes |
|
Power |
|
Power consumption (max) |
70 W |
|
Power consumption (typical) |
55 W |
|
Power supply |
450 W |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50/60 Hz |
|
Technical details |
|
Compliance certificates |
RCM, ICES, VCCI, Korean Industrial Standards (KS), Federal Communications Commission (FCC), RoHS, REACH |
|
Weight & dimensions |
|
Width |
482 mm |
|
Depth |
496.8 mm |
|
Height |
42.8 mm |
|
Weight |
8.5 kg |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 35 °C |
|
Operating relative humidity (H-H) |
8 - 80% |
|
Packaging content |
|
Rack mount kit |
Yes |
|
Cables included |
AC |
|
