General Information |
|
Summary |
Converged Next-Generation Firewall and SD-WAN
The FortiGate and FortiWiFi 50G series integrate firewalling, SD-WAN, and security in one appliance, making them perfect for building secure networks at distributed enterprise sites and transforming WAN architecture at any scale.
The 50G series is powered by FortiOS, the industry’s first converged networking and security operating system. This convergence enables businesses to efficiently and optimally secure today’s dynamic digital infrastructures.
As a cornerstone of the Fortinet Security Fabric platform, the FortiGate NGFW works seamlessly with FortiGuard AI-Powered Security Services to deliver coordinated, automated, end-to-end threat protection in real time.
The 50G family is built on the patented SD-WAN-based ASIC, which delivers unmatched performance over traditional CPUs with lower cost and reduced power consumption. This application-specific design and embedded multi-core processor further accelerate the convergence of networking and security functions in the 50G family to optimize secure connections and deliver a robust user experience at branch locations. |
|
Data transmission |
|
Firewall throughput |
6000 Mpps |
|
Firewall (UDP 1518) throughput |
5 Gbit/s |
|
IPSec VPN throughput |
4.5 Gbit/s |
|
IPS/IDS throughput |
2250 Mbit/s |
|
Threat protection throughput |
1100 Mbit/s |
|
SSL inspection throughput |
1300 Mbit/s |
|
Maximum firewall connections |
720000 |
|
Maximum firewall connections per second |
85000 |
|
Firewall latency |
2.42 µs |
|
Security policies (max) |
2000 |
|
Default number of virtual firewalls |
5 |
|
Maximum number of virtual firewalls |
5 |
|
Performance |
|
Mobile network generation |
5G |
|
Data network |
5G, HSPA+, LTE, UMTS, WCDMA |
|
MIMO |
Yes |
|
Security |
|
Security algorithms |
HTTPS, IPSec, SSL/TLS |
|
Management features |
|
LED indicators |
Yes |
|
Ports & interfaces |
|
Connectivity technology |
Wired |
|
Ethernet LAN (RJ-45) ports |
3 |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Console port |
RJ-45 |
|
Number of console ports |
1 |
|
WAN connection |
Ethernet (RJ-45) |
|
DC-in jack |
Yes |
|
Storage |
|
Storage media type |
SSD |
|
Total storage capacity |
64 GB |
|
SSD capacity |
64 GB |
|
Number of SSDs installed |
1 |
|
Design |
|
Rack mounting |
No |
|
Form factor |
Desktop |
|
Built-in display |
No |
|
Number of fans |
0 fan(s) |
|
Power |
|
AC input voltage |
100-240 V |
|
AC input frequency |
50/60 Hz |
|
Input current |
0.4 A |
|
DC input voltage |
12 V |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-35 - 70 °C |
|
Operating relative humidity (H-H) |
10 - 90% |
|
Storage relative humidity (H-H) |
10 - 90% |
|
Operating altitude |
0 - 3048 m |
|
Weight & dimensions |
|
Width |
216 mm |
|
Depth |
160 mm |
|
Height |
40.5 mm |
