Power |
|
Total power |
350 W |
|
AC input frequency |
50 - 60 Hz |
|
Power factor |
0.99 |
|
Power Factor Correction (PFC) type |
Active |
|
Max output current (+3.3V) |
12 A |
|
Max output current (+12V1) |
18 A |
|
Max output current (+12V2) |
18 A |
|
Max output current (+5V) |
20 A |
|
Max output current (-12V) |
0.3 A |
|
Max output current (+5Vsb) |
2.5 A |
|
Power protection features |
Over power, Over voltage, Short circuit |
|
Ports & interfaces |
|
Motherboard power connector |
20+4 pin ATX |
|
Peripheral (Molex) power connectors (4-pin) |
5 |
|
Number of SATA power connectors |
4 |
|
EPS power connector (4+4 pin) |
Yes |
|
PCI Express power connectors (6+2 pin) |
1 |
|
Floppy drive power connector |
1 |
|
Floppy disk drive connector |
Yes |
|
Cabling type |
Non-Modular |
|
Performance |
|
Purpose |
PC |
|
Power supply unit (PSU) form factor |
ATX |
|
80 PLUS certification |
80 PLUS Bronze |
|
ATX version |
2.3 |
|
Mean time between failures (MTBF) |
100000 h |
|
Design |
|
Product colour |
Grey |
|
Fan diameter |
12 cm |
|
Number of fans |
1 fan(s) |
|
Certificates |
|
Certification |
FCC, RCM, |
|
Safety regulation & standards |
|
Safety |
CB, CCC, cTUVus, TUV, BSMI |
|
Weight & dimensions |
|
Width |
150 mm |
|
Depth |
140 mm |
|
Height |
86 mm |
