General Information |
|
Summary |
2.5GbE connectivity and diverse storage options
The DS425+ features built-in 2.5GbE networking and supports both SATA SSDs and HDDs in 2.5"/3.5" internal bays, as well as M.2 NVMe drives via M.2 slots for use cache.1,5
Private cloud for seamless data access
Streamlined file management and collaboration
Store, sync, access, and share data from any device, wherever you are. Work seamlessly between different platforms and devices, and access your files through mobile apps, desktop clients, and a browser-based interface. Quickly and easily roll back files in case of accidental deletion, mistakes, malware, etc., with versioning. |
|
Storage |
|
Storage drives installed |
No |
|
Total installed storage capacity |
0 TB |
|
Number of storage drives installed |
0 |
|
Number of storage drives supported |
4 |
|
Installed storage drive type |
No |
|
Supported storage drive types |
HDD & SSD |
|
Storage drive capacity |
0 GB |
|
RAID support |
Yes |
|
Supported storage drive interfaces |
M.2, Serial ATA |
|
Storage drive sizes supported |
3.5,M.2,2.5 |
|
Maximum supported storage capacity |
80 TB |
|
Number of M.2 (M & B) slots |
2 |
|
RAID levels |
0, 1, 5, 6, 10, JBOD |
|
Hot-swap drive bays |
Yes |
|
Supported file systems |
BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
|
Processor |
|
Processor family |
Intel® Celeron® |
|
Processor manufacturer |
Intel |
|
Processor model |
J4125 |
|
Processor frequency |
2 GHz |
|
Processor boost frequency |
2.7 GHz |
|
Processor cores |
4 |
|
Memory |
|
Internal memory |
2 GB |
|
Internal memory type |
DDR4 |
|
Maximum RAM supported |
6 GB |
|
Memory slots |
1 |
|
ECC |
No |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN data rates |
2500 Mbit/s |
|
Wake-on-LAN ready |
Yes |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
2 |
|
USB port |
Yes |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
|
Design |
|
Cooling type |
Active |
|
Product colour |
Black |
|
Number of fans |
2 fan(s) |
|
Fan diameter |
9.2 cm |
|
Fan diameter 2 |
9.2 cm |
|
Drive bay locking |
Yes |
|
LED indicators |
Yes |
|
Performance |
|
Type |
NAS |
|
Device class |
Home & Home Office |
|
Backup function |
Yes |
|
Backup features |
Cloud, iSCSI LUN |
|
Multilingual support |
Yes |
|
Number of users |
512 user(s) |
|
Noise level |
21.6 dB |
|
Snapshot |
Yes |
|
Web-based management |
Yes |
|
Access Control List (ACL) |
Yes |
|
On/off switch |
Yes |
|
System log |
Yes |
|
Power |
|
Power supply location |
External |
|
Power supply unit (PSU) capacity |
90 W |
|
Power consumption (typical) |
28.25 W |
|
Power consumption (HDD standby) |
6.1 W |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50 - 60 Hz |
|
Weight & dimensions |
|
Width |
199 mm |
|
Depth |
223 mm |
|
Height |
166 mm |
|
Weight |
2.18 kg |
|
Packaging content |
|
External power adapter |
Yes |
|
Cables included |
AC, LAN (RJ-45) |
|
Power cables quantity |
1 |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Storage relative humidity (H-H) |
5 - 95% |
|
Other features |
|
Warranty period |
3 year(s) |
|
Compliance certificates |
RoHS |
