Processor |
|
Built-in processor |
No |
|
Processor socket |
Socket AM5 |
|
Memory |
|
Number of DIMM slots |
4 |
|
Supported memory types |
DDR5-SDRAM |
|
Maximum internal memory |
48 GB |
|
Memory form factor |
288-pin DIMM |
|
Memory voltage |
1.1 V |
|
ECC |
Yes |
|
Non-ECC |
Yes |
|
Storage |
|
Number of storage drives supported |
2 |
|
Hot-swap HDD bays |
Yes |
|
Number of 2.5" bays |
2 |
|
Graphics |
|
On-board graphics card model |
Aspeed AST2600 |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet interface type |
Gigabit Ethernet |
|
LAN controller |
Intel I210 |
|
Ports & interfaces |
|
USB 2.0 ports quantity |
0 |
|
Ethernet LAN (RJ-45) ports |
2 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
|
IPMI LAN (RJ-45) port |
Yes |
|
HDMI ports quantity |
1 |
|
DisplayPorts quantity |
1 |
|
VGA (D-Sub) ports quantity |
1 |
|
COM ports quantity |
1 |
|
Expansion slots |
|
PCI Express x16 (Gen 5.x) slots |
1 |
|
BIOS |
|
BIOS type |
UEFI AMI |
|
BIOS memory size |
256 Mbit |
|
ACPI version |
6.4 |
|
System Management BIOS (SMBIOS) version |
3.5 |
|
Design |
|
Chassis type |
Rack (2U) |
|
Power |
|
Power supply |
1200 W |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 35 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
20 - 90% |
|
Weight & dimensions |
|
Width |
430.4 mm |
|
Depth |
477.7 mm |
|
Height |
88 mm |
