Management features |
|
Switch type |
Managed |
|
Switch layer |
L3 |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
24 |
|
Basic switching RJ-45 Ethernet ports type |
10G Ethernet (100/1000/10000) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
Number of management ports |
1 pc(s) |
|
Console port |
RJ-45 |
|
SFP28 ports quantity |
4 |
|
USB 2.0 ports quantity |
1 |
|
Network |
|
Networking standards |
IEEE 802.1s, IEEE 802.3af, IEEE 802.3at |
|
10G support |
Yes |
|
Port mirroring |
Yes |
|
Flow control support |
Yes |
|
Data transmission |
|
MAC address table |
32768 entries |
|
Switching capacity |
680 Gbit/s |
|
Forwarding rate |
298 Mpps |
|
Jumbo frames support |
Yes |
|
Packet buffer memory |
4 MB |
|
Security |
|
DHCP features |
DHCP client, DHCP server, DHCPv6 relay |
|
Access Control List (ACL) |
Yes |
|
Security algorithms |
SNMP |
|
Protocols |
|
Routing protocols |
OSPFv2, OSPFv3, VRRP |
|
IPv4 & IPv6 features |
Dual stack IPv4/IPv6, IPv6 TFTP |
|
Design |
|
Stackable |
Yes |
|
Product colour |
Black |
|
Performance |
|
Mean time between failures (MTBF) |
286.4952 h |
|
Power |
|
Power source |
AC |
|
Power supply included |
Yes |
|
Number of power supply units |
2 |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50/60 Hz |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
10 - 90% |
|
Storage relative humidity (H-H) |
5 - 90% |
|
Heat dissipation |
3439.64 BTU/h |
|
Weight & dimensions |
|
Width |
440 mm |
|
Depth |
470 mm |
|
Height |
44 mm |
|
Weight |
6.48 kg |
