Ubiquiti U7 Pro XG WiFi 7 AP
|
|
Regularly: $278.00
On Sale: $269.66
Sale Ends:
September 21st, 2025
Manufacturer:
Ubiquiti
WiFi 7 (802.11a/b/g/n/ac/ax/be), 6 GHz, 140 m² (1,500 ft²), 10/5/2.5/1 GbE, PoE+, 300+ clients, 206 x 32.5 mm, 750 g
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
60144540
|
U7-Pro-XG-B
|
810177162124 |
Active
|
Details
|
General Information |
|
Summary |
Ceilingmounted 6stream WiFi 7 AP with 10/5/2.5/1 GbE support. |
|
Features |
|
2.4 GHz |
Yes |
|
5 GHz |
Yes |
|
6 GHz |
Yes |
|
Maximum data transfer rate |
5800 Mbit/s |
|
Maximum data transfer rate (2.4 GHz) |
688 Mbit/s |
|
Maximum data transfer rate (5 GHz) |
4300 Mbit/s |
|
Maximum data transfer rate (6 GHz) |
5800 Mbit/s |
|
Ethernet LAN data rates |
1000,2500,5000,10000 Mbit/s |
|
Frequency band |
2.4, 5, 6 GHz |
|
Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v |
|
Coverage area |
140 m² |
|
Number of users |
300 user(s) |
|
MIMO |
Yes |
|
MIMO type |
Multi User MIMO |
|
Spatial streams |
6 |
|
Fit AP mode features |
Hotspot 2.0 |
|
Fast roaming |
Yes |
|
VLAN support |
Yes |
|
Rate limiting |
Yes |
|
Wireless meshing |
Yes |
|
Band steering |
Yes |
|
Maximum Tx power (2.4 GHz) |
23 dBmW |
|
Maximum Tx power (5 GHz) |
26 dBmW |
|
Maximum Tx power (6 GHz) |
24 dBmW |
|
Security |
|
Security algorithms |
PPSK |
|
Management features |
|
Access point management |
Wi-Fi schedule |
|
Ports & interfaces |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Power |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet (PoE) type supported |
PoE+ |
|
Power consumption (max) |
22 W |
|
Design |
|
Placement |
Ceiling, Wall |
|
Product colour |
Black |
|
Housing material |
Metal, Polycarbonate (PC) |
|
Reset button |
Yes |
|
LED indicators |
Status |
|
Antenna |
|
Antenna type |
Internal |
|
Antenna gain level (max) |
6 dBi |
|
Certificates |
|
Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC) |
|
Weight & dimensions |
|
Width |
206 mm |
|
Depth |
32.5 mm |
|
Height |
206 mm |
|
Weight |
750 g |
|
Packaging content |
|
Quantity per pack |
1 pc(s) |
|
Mounting kit |
Yes |
|
Operational conditions |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Operating temperature (T-T) |
-30 - 40 °C |
|
