General Information |
|
Summary |
2Port DVI Video/Audio Splitter |
|
Ports & interfaces |
|
Video ports quantity |
3 |
|
Video port type |
DVI |
|
Video out |
2x DVI-I |
|
Video in |
1 x DVI-I Female |
|
Audio ports quantity |
3 |
|
Connector(s) |
2 |
|
DC-in jack |
Yes |
|
Features |
|
Maximum resolution |
1920 x 1200 pixels |
|
Product colour |
Black, Grey |
|
3D |
No |
|
Maximum operating distance |
5 m |
|
Remote control included |
No |
|
Rack mounting |
Yes |
|
HDCP |
Yes |
|
Supported graphics resolutions |
1920 x 1200 (WUXGA) |
|
Power LED |
Yes |
|
LED indicators |
Activity |
|
Windows operating systems supported |
Yes |
|
Mac operating systems supported |
Yes |
|
Mac compatibility |
Yes |
|
Power |
|
AC input voltage |
5.3 V |
|
Power consumption (typical) |
2.36 W |
|
USB powered |
No |
|
Weight & dimensions |
|
Dimensions (WxDxH) |
210 x 88 x 55.5 mm |
|
Weight |
620 g |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Operating relative humidity (H-H) |
0 - 80% |
|
Technical details |
|
Audio input |
1 |
|
Audio output |
2 |
|
Resolution |
1920 x 1200 pixels |
|
Connector type |
DVI-I Female |
|
Number of connectors |
2 |
|
Maximum cable length |
5 m |
|
Cascadable |
Yes |
|
Maximum video resolution |
1920 x 1200 pixels |
|
Exterior material |
Plastic |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
