General Information |
|
Summary |
A Revolutionary Laptop With Evolutionary Features
Expect Excellence- 14'' AI PC for business — imagined with Intel®
- Lenovo Aura Edition features for optimized productivity & day-to-day experience
- Our thinnest & lightest 14'' ThinkPad X1 yet — less than 1kg
- Super-long battery life & customer-replaceable battery for extended lifecycle
- Lowest carbon footprint X1 yet
Copilot+ PC experiences are coming. Requires free updates available starting later this year. Timing varies by device and region. See aka.ms/copilotpluspcs. |
|
Design |
|
Product type |
Laptop |
|
Product colour |
Black |
|
Form factor |
Clamshell |
|
Colour name |
Black, Paint |
|
Housing material |
Aluminium |
|
Display |
|
Display diagonal |
35.6 cm (14") |
|
Display resolution |
1920 x 1200 pixels |
|
Touchscreen |
No |
|
HD type |
WUXGA |
|
Panel type |
IPS |
|
LED backlight |
Yes |
|
Native aspect ratio |
16:10 |
|
Anti-glare screen |
Yes |
|
Display brightness |
500 cd/m² |
|
RGB colour space |
sRGB |
|
Colour gamut |
100% |
|
Maximum refresh rate |
60 Hz |
|
Processor |
|
Processor family |
Intel Core Ultra 5 |
|
Processor manufacturer |
Intel |
|
Processor model |
225U |
|
Processor generation |
Intel Core Ultra (Series 2) |
|
Processor cores |
12 |
|
Processor threads |
14 |
|
Processor boost frequency |
4.8 GHz |
|
Performance cores |
2 |
|
Efficient cores |
8 |
|
Low Power Efficient-cores |
2 |
|
Performance-core Max Turbo Frequency |
4.8 GHz |
|
Efficient-core Max Turbo Frequency |
3.8 GHz |
|
Low Power Efficient-core Max Turbo Frequency |
2.4 GHz |
|
Performance-core base frequency |
1.5 GHz |
|
Efficient-core base frequency |
1.3 GHz |
|
Low Power Efficient-core Base Frequency |
700 MHz |
|
Processor cache |
12 MB |
|
Processor base power |
15 W |
|
Maximum turbo power |
57 W |
|
Neural processor unit (NPU) |
|
Neural processor unit (NPU) |
Intel AI Boost |
|
Sparsity support |
Yes |
|
Windows Studio effects support |
Yes |
|
AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
|
Memory |
|
Internal memory |
16 GB |
|
Maximum internal memory |
16 GB |
|
Internal memory type |
LPDDR5x-SDRAM |
|
Memory clock speed |
8400 MHz |
|
Memory form factor |
On-board |
|
Storage |
|
Total storage capacity |
512 GB |
|
Storage media |
SSD |
|
Optical drive type |
No |
|
Total SSDs capacity |
512 GB |
|
Number of SSDs installed |
1 |
|
SSD capacity |
512 GB |
|
SSD interface |
PCI Express 4.0 |
|
NVMe |
Yes |
|
SSD form factor |
M.2 |
|
Card reader integrated |
No |
|
Graphics |
|
On-board graphics card |
Yes |
|
Discrete graphics card |
No |
|
Discrete graphics card model |
Not available |
|
On-board graphics card model |
Intel Graphics |
|
On-board GPU manufacturer |
Intel |
|
On-board graphics card family |
Intel Graphics |
|
Audio |
|
Audio chip |
Realtek ALC3306 |
|
Number of built-in speakers |
2 |
|
Speaker power |
2 W |
|
Built-in microphone |
Yes |
|
Number of microphones |
2 |
|
Camera |
|
Front camera |
Yes |
|
Front camera resolution |
1920 x 1080 pixels |
|
Front camera HD type |
Full HD |
|
Infrared (IR) camera |
Yes |
|
Privacy camera |
Yes |
|
Privacy type |
Privacy shutter |
|
Network |
|
Mobile network connection |
No |
|
Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
|
Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
|
Antenna type |
2x2 |
|
WLAN controller model |
Intel Wi-Fi 6E AX211 |
|
WLAN controller manufacturer |
Intel |
|
Ethernet LAN |
No |
|
Bluetooth |
Yes |
|
Bluetooth version |
5.3 |
|
Near Field Communication (NFC) |
No |
|
WWAN |
Not installed |
|
Ports & interfaces |
|
USB 2.0 ports quantity |
0 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
|
HDMI ports quantity |
1 |
|
HDMI version |
2.1 |
|
Thunderbolt 4 ports quantity |
2 |
|
Intel® Thunderbolt 4 |
Yes |
|
Combo headphone/mic port |
Yes |
|
USB Sleep-and-Charge |
Yes |
|
Performance |
|
Motherboard chipset |
Intel SoC |
|
Keyboard |
|
Numeric keypad |
No |
|
Pointing device |
ThinkPad UltraNav |
|
Keyboard backlit |
Yes |
|
Software |
|
Operating system installed |
Windows 11 Pro |
|
Operating system architecture |
64-bit |
|
Bundled software |
Intel Connectivity Performance Suite |
|
Battery |
|
Battery capacity |
57 Wh |
|
Power |
|
USB Type-C charging port |
Yes |
|
AC adapter power |
65 W |
|
USB Power Delivery (USB PD) |
Yes |
|
Security |
|
Cable lock slot |
Yes |
|
Cable lock slot type |
Kensington |
|
Fingerprint reader |
Yes |
|
Smart card reader |
No |
|
Windows Hello |
Yes |
|
Trusted Platform Module (TPM) |
Yes |
|
Trusted Platform Module (TPM) version |
2.0 |
|
Certificates |
|
Certification |
ENERGY STAR,TCO,EPEAT Gold,RoHS |
|
Weight & dimensions |
|
Weight |
1.01 kg |
|
Width |
312.8 mm |
|
Depth |
214.8 mm |
|
Height (front) |
8.38 mm |
|
Height (rear) |
1.48 cm |
|
Packaging content |
|
AC adapter included |
Yes |
