General Information |
|
Summary |
BIRTH OF A LEGEND
ASUS made its name on PC components like motherboards and graphics cards, so we know what a quality PC looks like. We carefully designed this entire system from the ground up, rigorously tested it for rock-solid stability and reliability, and tuned it for incredible power efficiency, and thermal performance. |
|
Processor |
|
Processor family |
Intel Core Ultra 9 |
|
Processor manufacturer |
Intel |
|
Processor model |
285K |
|
Processor generation |
Intel Core Ultra (Series 2) |
|
Processor cores |
24 |
|
Processor threads |
24 |
|
Processor boost frequency |
5.7 GHz |
|
Performance cores |
8 |
|
Efficient cores |
16 |
|
Performance-core Max Turbo Frequency |
5.5 GHz |
|
Efficient-core Max Turbo Frequency |
4.6 GHz |
|
Performance-core base frequency |
3.7 GHz |
|
Efficient-core base frequency |
3.2 GHz |
|
Processor cache |
36 MB |
|
Processor cache type |
Smart Cache |
|
Processor base power |
125 W |
|
Maximum turbo power |
250 W |
|
Neural processor unit (NPU) |
|
Neural processor unit (NPU) |
Intel AI Boost |
|
Sparsity support |
Yes |
|
Windows Studio effects support |
Yes |
|
AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
|
Total processor performance up to |
36 TOPs |
|
NPU performance up to |
13 TOPs |
|
GPU performance up to |
8 TOPs |
|
Memory |
|
Internal memory |
32 GB |
|
Maximum internal memory |
128 GB |
|
Internal memory type |
DDR5-SDRAM |
|
Memory slots |
4x DIMM |
|
Storage |
|
Total storage capacity |
2 TB |
|
Optical drive type |
No |
|
Storage media |
SSD |
|
Total SSDs capacity |
2 TB |
|
Number of SSDs installed |
1 |
|
SSD capacity |
2 TB |
|
SSD interface |
PCI Express 4.0 |
|
NVMe |
Yes |
|
SSD form factor |
M.2 |
|
M.2 SSD size |
2280 (22 x 80 mm) |
|
Graphics |
|
Discrete graphics card |
Yes |
|
On-board graphics card |
Yes |
|
Discrete graphics card model |
NVIDIA GeForce RTX 5070 Ti |
|
On-board graphics card model |
Intel Graphics |
|
Discrete GPU manufacturer |
NVIDIA |
|
Discrete graphics card memory |
16 GB |
|
Discrete graphics memory type |
GDDR7 |
|
On-board GPU manufacturer |
Intel |
|
On-board graphics card family |
Intel Graphics |
|
Graphics card HDMI ports quantity |
1 |
|
Graphics card DisplayPorts quantity |
3 |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN data rates |
1000 Mbit/s |
|
Ports & interfaces |
|
USB 2.0 ports quantity |
4 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
|
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
|
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
|
Thunderbolt 3 ports quantity |
0 |
|
HDMI ports quantity |
0 |
|
DisplayPorts quantity |
1 |
|
DisplayPort version |
1.4 |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Microphone in |
Yes |
|
Headphone outputs |
1 |
|
Expansion slots |
|
PCI Express x16 (Gen 4.x) slots |
3 |
|
PCI Express x16 (Gen 5.x) slots |
1 |
|
Design |
|
Chassis type |
Tower |
|
Product colour |
Black |
|
Colour name |
Black |
|
Performance |
|
Product type |
PC |
|
Market positioning |
Gaming |
|
Motherboard chipset |
Intel B860 |
|
Audio system |
High Definition Audio |
|
Audio output channels |
7.1 channels |
|
Software |
|
Operating system installed |
Windows 11 Home |
|
Operating system architecture |
64-bit |
|
Trial software |
1-month trial for new Microsoft 365 customers. Credit card required. |
|
Power |
|
Power supply |
850 W |
|
80 PLUS certification |
80 PLUS Gold |
|
Weight & dimensions |
|
Width |
240 mm |
|
Depth |
509.2 mm |
|
Height |
479.6 mm |
|
Weight |
18 kg |
|
Display |
|
Display included |
No |
