General Information |
|
Summary |
The Aegis RS series is the gold standard for anyone looking to take their gaming to the next level. Combining breakthrough technologies with up to the latest Intel® Core™ processors and MSI GeForce RTX™40 series graphics card, Aegis RS brings Pro-level gaming performance from the get-go. Assembled in the USA with quality and modularity in mind, the Aegis RS series gives gamers ultimate performance and flexible system management through standardized MSI components and parts. Want to upgrade your GPU, RAM, or Storage capacity in a few years? The option is there with MSI systems, something not always possible with others. |
|
Processor |
|
Processor family |
Intel® Core™ i7 |
|
Processor manufacturer |
Intel |
|
Processor model |
i7-14700F |
|
Processor generation |
Intel® Core™ i7 (14th gen) |
|
Processor cores |
20 |
|
Processor threads |
28 |
|
Processor boost frequency |
5.4 GHz |
|
Performance cores |
8 |
|
Efficient cores |
12 |
|
Performance-core Max Turbo Frequency |
5.3 GHz |
|
Efficient-core Max Turbo Frequency |
4.2 GHz |
|
Performance-core base frequency |
2.1 GHz |
|
Efficient-core base frequency |
1.5 GHz |
|
Processor cache |
33 MB |
|
Processor cache type |
Smart Cache |
|
Processor base power |
65 W |
|
Maximum turbo power |
219 W |
|
Memory |
|
Internal memory |
32 GB |
|
Internal memory type |
DDR5-SDRAM |
|
Memory layout (slots x size) |
2 x 16 GB |
|
Storage |
|
Total storage capacity |
2 TB |
|
Optical drive type |
No |
|
Storage media |
SSD |
|
Total SSDs capacity |
2 TB |
|
Number of SSDs installed |
1 |
|
SSD capacity |
2 TB |
|
SSD interface |
PCI Express 4.0 |
|
NVMe |
Yes |
|
SSD form factor |
M.2 |
|
Graphics |
|
Discrete graphics card |
Yes |
|
On-board graphics card |
No |
|
Discrete graphics card model |
NVIDIA GeForce RTX 3060 |
|
On-board graphics card model |
Not available |
|
Discrete GPU manufacturer |
NVIDIA |
|
Discrete graphics card memory |
8 GB |
|
Network |
|
Ethernet LAN |
Yes |
|
Wi-Fi |
Yes |
|
Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
|
Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
|
Wi-Fi standards |
Wi-Fi 7 (802.11be) |
|
Ports & interfaces |
|
USB 2.0 ports quantity |
4 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
|
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
|
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
|
Thunderbolt 3 ports quantity |
0 |
|
HDMI ports quantity |
1 |
|
USB 3.2 Gen 2x2 Type-C ports quantity |
2 |
|
HDMI version |
2.1 |
|
DisplayPorts quantity |
3 |
|
DisplayPort version |
1.4a |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Microphone in |
Yes |
|
Headphone outputs |
1 |
|
Design |
|
Chassis type |
Desktop |
|
Product colour |
Black |
|
Performance |
|
Product type |
PC |
|
Market positioning |
Gaming |
|
Motherboard chipset |
Intel Z790 |
|
Audio chip |
Realtek ALC4080 |
|
Audio output channels |
7.1 channels |
|
Software |
|
Operating system installed |
Windows 11 Home |
|
Power |
|
Power supply |
750 W |
|
80 PLUS certification |
80 PLUS Gold |
|
Weight & dimensions |
|
Width |
214.9 mm |
|
Depth |
430 mm |
|
Height |
450 mm |
|
Weight |
13.6 kg |
|
Display |
|
Display included |
No |
