Management features |
|
Switch type |
Managed |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
2.5G Ethernet (100/1000/2500) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
SFP+ module slots quantity |
2 |
|
Network |
|
Networking standards |
IEEE 802.1p |
|
10G support |
No |
|
Port mirroring |
Yes |
|
Flow control support |
Yes |
|
Link aggregation |
Yes |
|
Broadcast storm control |
Yes |
|
Auto MDI/MDI-X |
Yes |
|
Data transmission |
|
MAC address table |
16000 entries |
|
Switching capacity |
80 Gbit/s |
|
Forwarding rate |
59.52 Mpps |
|
Store-and-forward |
Yes |
|
Jumbo frames support |
Yes |
|
Packet buffer memory |
0.64 MB |
|
Security |
|
DHCP features |
DHCP client |
|
IGMP snooping |
Yes |
|
Design |
|
Rack mounting |
Yes |
|
Form factor |
Desktop/Wall-Mounting |
|
Product colour |
Black |
|
LED indicators |
Yes |
|
Performance |
|
Firmware upgradeable |
Yes |
|
Power |
|
Power source |
DC |
|
Power supply included |
Yes |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
No |
|
Operational conditions |
|
Operating temperature (T-T) |
-5 - 40 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
10 - 90% |
|
Storage relative humidity (H-H) |
5 - 90% |
|
Weight & dimensions |
|
Width |
209 mm |
|
Depth |
126 mm |
|
Height |
26 mm |
|
Packaging content |
|
Quick start guide |
Yes |
