General Information |
|
Summary |
HD LCD 200-240V HW OR CORD RMCARD205 RT 3YR WTY |
|
Features |
|
UPS topology |
Double-conversion (Online) |
|
Output power capacity |
5 kVA |
|
Output power |
5000 W |
|
Waveform |
Sine |
|
Input operation voltage (min) |
120 V |
|
Input operation voltage (max) |
280 V |
|
Input frequency |
40/70 Hz |
|
Output operation voltage (min) |
120 V |
|
Output operation voltage (max) |
240 V |
|
Output frequency |
50/60 Hz |
|
Power factor |
1 |
|
Input power factor |
0.99 |
|
Output power factor |
1 |
|
Crest factor |
3:1 |
|
Output voltage Total Harmonic Distortion (THD) |
5% |
|
Ports & interfaces |
|
AC outlet types |
Hardwire, NEMA L6-30P |
|
Power plug |
Hardwire |
|
AC outlets quantity |
4 AC outlet(s) |
|
Modem (RJ-11) ports |
1 |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Battery |
|
Battery technology |
Sealed Lead Acid (VRLA) |
|
Battery capacity |
6 Ah |
|
Battery voltage |
12 V |
|
Number of batteries supported |
12 |
|
Battery recharge time |
4 h |
|
Hot-swap battery |
Yes |
|
Cold start |
Yes |
|
Replacement battery cartridge |
RB1260X12 |
|
Design |
|
Form factor |
Rackmount |
|
Product colour |
Black |
|
Housing material |
Steel |
|
Rack capacity |
2U |
|
Display type |
LCD |
|
LED indicators |
Battery replacement, Fault, Power |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-20 - 45 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 15000 m |
|
Certificates |
|
Compliance certificates |
RoHS |
|
Packaging content |
|
Rack mount kit |
Yes |
|
Cables included |
USB cable |
|
Weight & dimensions |
|
Width |
431 mm |
|
Depth |
718 mm |
|
Height |
86 mm |
|
Weight |
41.9 kg |
|
Packaging data |
|
Package width |
599.4 mm |
|
Package depth |
1099.8 mm |
|
Package height |
215.9 mm |
|
Package weight |
52 kg |
|
Sustainability |
|
Sustainability compliance |
Yes |
