General Information |
|
Summary |
60 GHz wireless pointtopoint bridge with a 10G SFP+ uplink for maximum performance and a 5 GHz backup radio.500 m 1,640 ft maximum range60 GHz 5 GHz dualradio redundancy1 10G SFP+ and 1 GbE PoE++ portPowered using PoE++Builtin LED alignment indicators |
|
Data transmission |
|
Maximum data transfer rate |
6000 Mbit/s |
|
Maximum transfer distance |
500 m |
|
Wireless LAN features |
|
Wi-Fi |
Yes |
|
Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN interface type |
Gigabit Ethernet |
|
Ethernet LAN data rates |
1000 Mbit/s |
|
Cabling technology |
10/100/1000Base-T(X) |
|
Ports & interfaces |
|
Connectivity technology |
Wired & Wireless |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Security |
|
Security algorithms |
WPA2-AES |
|
Features |
|
Product type |
Network bridge |
|
Material |
Aluminium, Polycarbonate (PC) |
|
Mounting type |
Pole |
|
Product colour |
White |
|
LED indicators |
Yes |
|
Reset button |
Yes |
|
International Protection (IP) code |
IPX6 |
|
Power |
|
Power source type |
PoE |
|
Power consumption (max) |
31.2 W |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet (PoE) voltage |
48 V |
|
Operational conditions |
|
Operating temperature (T-T) |
-40 - 131 °F |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Certificates |
|
Certification |
FCC, IC, CE, terragraph |
|
Weight & dimensions |
|
Width |
191.8 mm |
|
Depth |
191.8 mm |
|
Height |
59 mm |
|
Weight |
1.7 kg |
|
Packaging content |
|
Mounting bracket(s) included |
Yes |
|
Power supply included |
Yes |
|
Manual |
Yes |
|
Packaging data |
|
Quantity per pack |
2 pc(s) |
