General Information |
|
Summary |
Industrial
Durable Industrial Switches
Rugged, easy-to-deploy switches that are certified to be reliable even in extreme environments. |
|
Management features |
|
Switch type |
Managed |
|
Switch layer |
L2/L3 |
|
Quality of Service (QoS) support |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
8 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
SFP module slots quantity |
4 |
|
Network |
|
Networking standards |
IEEE 802.3af, IEEE 802.3at |
|
10G support |
No |
|
Link aggregation |
Yes |
|
Ethernet LAN data rates |
10,1000,100 Mbit/s |
|
VLAN support |
Yes |
|
Virtual LAN features |
Port-based VLAN, Voice VLAN |
|
Number of VLANs |
4000 |
|
Data transmission |
|
MAC address table |
8000 entries |
|
Switching capacity |
24 Gbit/s |
|
Forwarding rate |
17.86 Mpps |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9000 |
|
Security |
|
Security algorithms |
SNMP, SNMPv2, SNMPv3 |
|
MAC address filtering |
Yes |
|
Design |
|
Form factor |
DIN rail |
|
Product colour |
Black |
|
LED indicators |
Yes |
|
International Protection (IP) code |
IP40 |
|
DIN rail mounting |
Yes |
|
Power |
|
Power source |
DC |
|
Power supply included |
Yes |
|
DC input voltage |
48 - 55 V |
|
Power consumption (max) |
251.6 W |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet (PoE) type supported |
PoE+ |
|
Power over Ethernet plus (PoE+) ports quantity |
8 |
|
Power over Ethernet (PoE) power per port |
30 W |
|
Total Power over Ethernet (PoE) budget |
240 W |
|
Operational conditions |
|
Operating temperature (T-T) |
-40 - 75 °C |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Weight & dimensions |
|
Width |
44 mm |
|
Depth |
107 mm |
|
Height |
164 mm |
|
Weight |
820 g |
