Netgear M4100-12GF 12-Port Gigabit Managed Switch
|
|
Price: $1018.00
Manufacturer:
Netgear
Managed, PoE, Gigabit Ethernet, 12x RJ-45, 12x SFP, L2+, USB, RS-232, 128MB RAM, 32MB Flash, QoS, DHCP, VLAN, 160.6W, 3.665kg, grey
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
60544783
|
GSM7212F-100NES
|
6064490809264 |
Active
|
Details
|
General Information |
|
Summary |
The NETGEAR ProSafe Gigabit L2+ Managed Switch GSM7212F for "Intelligent Edge" distribution consists of 12 ports combo, dual-speed SFP with fiber connectivity, including 4 ports with PoE+ connectivity. Intelligent Edge series deliver a secure and flexible access in campus, commercial and enterprise converged environments: Wireless access points, IP telephony and video-surveillance.
Intelligent Edge
Combining superior resiliency and advanced security, GSM7212F provides comprehensive Layer 2, Lite Layer 3 and Layer 4 switching, including 16K MAC table size, 64 routing interfaces and 16 static routes.
Unified Communications – Voice over IP
The NETGEAR ProSafe "Intelligent Edge" simplifies converged data deployments with state-of-the-art capabilities. CoS Layer 2 prioritization and DiffServ Layer 3 & 4 policies allow for 1Kbps ingress and egress TCP/UDP granularity. LLDP-MED (Media Endpoint Discovery) automatically configures IP phones QoS and VLAN settings.
Unified Communications – Video Streams
IGMP filtering and querier ensure multicast streams are only delivered to interested receivers, preventing flooding even without a dedicated multicast router. When receivers are in different VLANs, Multicast VLAN registration (MVR) uses a dedicated multicast VLAN to forward multicast streams and avoid duplication for clients in different VLANs.
Outstanding Value
With its high-value price point, industry-standard command line interface (CLI) and single-pane-of-glass NMS200 management platform (mass-configuration support), NETGEAR ProSafe "Intelligent Edge" yields a high return on investment. GSM7212F is backed by the NETGEAR ProSafe Lifetime Hardware Warranty+, ProSupport Lifetime 24x7 Advanced Technical Support, and 3-Year Next Business Day Onsite Hardware Replacement. |
|
Management features |
|
Switch type |
Managed |
|
Switch layer |
L2+ |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
System event log |
Yes |
|
MIB support |
MIB-II, Bridge MIB, Etherlike-MIB, SMIv2, VLAN MIB, Client MIB, Entity MIB v2, RMON-MIB, PAE-MIB, LLDP MIB |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
12 |
|
SFP/SFP+ slots quantity |
12 |
|
SFP module slots quantity |
12 |
|
Fiber ports quantity |
12 |
|
Fiber optic connector |
SFP |
|
Console port |
RS-232 |
|
USB 2.0 ports quantity |
1 |
|
Power connector |
DC-in jack |
|
Network |
|
Networking standards |
IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|
10G support |
Yes |
|
Copper ethernet cabling technology |
1000BASE-T, 1000BASE-TX, 100BASE-T, 100BASE-TX, 10BASE-T |
|
Port mirroring |
Yes |
|
IP routing |
Yes |
|
Flow control support |
Yes |
|
Link aggregation |
Yes |
|
Broadcast storm control |
Yes |
|
Rate limiting |
Yes |
|
Spanning tree protocol |
Yes |
|
Number of VLANs |
64 |
|
Optical fiber |
|
Fiber ethernet cabling technology |
1000BASE‑LX, 1000BASE‑SX, 100BASE-FX |
|
Data transmission |
|
MAC address table |
16000 entries |
|
Switching capacity |
24 Gbit/s |
|
Supported data transfer rates |
10/100/1000 Mbps |
|
Throughput |
17.8 Mpps |
|
Store-and-forward |
Yes |
|
Number of trunks |
12 |
|
Number of queues |
8 |
|
Number of static routes |
16 |
|
Maximum data transfer rate |
10 Gbit/s |
|
Jumbo frames support |
Yes |
|
Packet buffer memory |
12 MB |
|
Security |
|
DHCP features |
DHCP server, DHCP client |
|
Access Control List (ACL) |
Yes |
|
IGMP snooping |
Yes |
|
Security algorithms |
802.1x RADIUS, EAP, HTTPS, SSL/TLS, WPA-AES |
|
MAC address filtering |
Yes |
|
Static port security |
Yes |
|
SSH/SSL support |
Yes |
|
Multicast features |
|
Multicast support |
Yes |
|
Protocols |
|
Management protocols |
SNMP v1/2/3, SMI v1/2, HTTP 1.1 |
|
Data link protocols |
LLDP |
|
Supported network protocols |
IP, IPv4, IPv6, TCP/UDP, TFTP, DoS, ICMP, ARP, BOOTP, SNTP, SFTP, BSD, Telnet |
|
Design |
|
Rack mounting |
Yes |
|
Stackable |
Yes |
|
Product colour |
Grey |
|
Safety |
CE, CSA, UL/cUL, EN |
|
Performance |
|
Built-in processor |
Yes |
|
Processor model |
Broadcom BCM53003 |
|
Processor frequency |
600 MHz |
|
Memory type |
RAM |
|
Internal memory |
128 MB |
|
Flash memory |
32 MB |
|
Noise level |
48 dB |
|
Mean time between failures (MTBF) |
670956 h |
|
Power |
|
Power consumption (typical) |
150 W |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet plus (PoE+) ports quantity |
4 |
|
Other features |
|
Latency |
3.1 - 9 |
|
Dimensions (WxDxH) |
440 x 257 x 44 mm |
|
Connectivity technology |
Wired |
|
Networking features |
Gigabit Ethernet |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Non-operating altitude |
0 - 3000 m |
|
Weight & dimensions |
|
Weight |
3.67 kg |
|
Certificates |
|
Certification |
CE, FCC, VCCI, EN (CISPR 22), C-Tick |
|
