General Information |
|
Summary |
Experience the most versatile and easy to manage switches in the market
As a leading provider of network equipment for SMBs, NETGEAR understands the importance of reliable and high performance networks. With the growth of virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, SMB networks need to extend beyond simple reliability to simpler management and remote monitoring to ensure your network is “always up”. NETGEAR also understands that small business owners shouldn’t have to understand networking and IT; they need a network that’s easy-to-setup and is reliable, so they can focus on their business, not their network. To that end, NETGEAR is introducing our most versatile and easy-to-manage switches ever, NETGEAR Insight Managed Smart Cloud switches.
The Insight Managed Smart Cloud Gigabit Ethernet/10G SFP+ Switches are the first switches from NETGEAR with anywhere configuration and management. Using either the NETGEAR Insight app on your mobile device or tablet, or the Insight Cloud Portal from your PC, Mac, or tablet, you can quickly discover, setup, monitor and manage your Smart Cloud Switches from anywhere in the world! With their remote cloud manageability, sleek design, and combination of Gigabit copper, Gigabit SFP fiber, and 10G SFP+ fiber ports, Insight Managed Smart Cloud Switches are the most versatile switches in the market for any environment. Whether at home, out of the office or on a business trip, you can still manage and monitor your network as if you were right there. |
|
Management features |
|
Switch type |
Managed |
|
Switch layer |
L2/L3/L4 |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
ARP inspection |
Yes |
|
System event log |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
24 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Installed SFP modules quantity |
2 |
|
Installed SFP+ modules quantity |
2 |
|
USB 2.0 ports quantity |
1 |
|
Power connector |
DC-in jack |
|
Network |
|
Networking standards |
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|
10G support |
No |
|
Number of VLANs |
256 |
|
Data transmission |
|
MAC address table |
16000 entries |
|
Switching capacity |
92 Gbit/s |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
9000 |
|
Security |
|
DHCP features |
DHCP client |
|
Access Control List (ACL) |
Yes |
|
Access Control List (ACL) rules |
100 |
|
Multicast features |
|
Multicast support |
Yes |
|
Number of multicast groups filtered |
512 |
|
Design |
|
Rack mounting |
Yes |
|
Form factor |
1U |
|
Product colour |
White |
|
LED indicators |
Yes |
|
Number of fans |
2 fan(s) |
|
Performance |
|
Processor frequency |
400 MHz |
|
Internal memory |
1.5 MB |
|
Noise level |
39 dB |
|
Mean time between failures (MTBF) |
629962 h |
|
Power |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50 - 60 Hz |
|
Input current |
1 A |
|
Power consumption (typical) |
25.5 W |
|
Power consumption (max) |
437.1 W |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet (PoE) ports quantity |
24 |
|
Total Power over Ethernet (PoE) budget |
390 W |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 50 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Storage relative humidity (H-H) |
0 - 95% |
|
Operating altitude |
0 - 3000 m |
|
Heat dissipation |
1491.45 BTU/h |
|
Weight & dimensions |
|
Width |
440 mm |
|
Depth |
224 mm |
|
Height |
44 mm |
|
Weight |
3.79 kg |
|
Packaging content |
|
Cables included |
AC |
|
Quick start guide |
Yes |
|
Rack mount kit |
Yes |
