Processor |
|
Processor family |
Intel® Xeon® |
|
Processor cores |
24 |
|
Processor socket |
LGA 4710 |
|
Package type |
Box |
|
Processor manufacturer |
Intel |
|
Processor model |
658X |
|
Processor base frequency |
3 GHz |
|
Processor operating modes |
64-bit |
|
Processor threads |
48 |
|
System bus rate |
0 GT/s |
|
Intel® UPI Speed |
0 GT/s |
|
Performance cores |
24 |
|
Efficient cores |
0 |
|
Processor boost frequency |
4.9 GHz |
|
Processor cache |
144 MB |
|
Thermal Design Power (TDP) |
250 W |
|
Processor base power |
250 W |
|
Maximum turbo power |
300 W |
|
Processor codename |
Granite Rapids |
|
Processor ARK ID |
244337 |
|
Memory |
|
Memory channels |
Octa-channel |
|
Maximum internal memory supported by processor |
4 TB |
|
Memory types supported by processor |
DDR5-SDRAM |
|
Memory clock speeds supported by processor |
6400 MHz |
|
ECC |
Yes |
|
Graphics |
|
On-board graphics card |
No |
|
Discrete graphics card |
No |
|
On-board graphics card model |
Not available |
|
Discrete graphics card model |
Not available |
|
Features |
|
Execute Disable Bit |
Yes |
|
Market segment |
Workstation |
|
Maximum number of PCI Express lanes |
128 |
|
PCI Express slots version |
5.0 |
|
Supported instruction sets |
AMX, AVX 2.0, AVX-512, SSE4.1, SSE4.2 |
|
Scalability |
1S |
|
CPU configuration (max) |
1 |
|
Embedded options available |
Yes |
|
Direct Media Interface (DMI) Revision |
4.0 |
|
Processor special features |
|
Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
|
Intel® Turbo Boost Technology |
2.0 |
|
Intel® AES New Instructions (Intel® AES-NI) |
Yes |
|
Intel Trusted Execution Technology |
Yes |
|
Intel® Speed Shift Technology |
Yes |
|
Intel® Turbo Boost Max Technology 3.0 frequency |
4.9 GHz |
|
Intel® Turbo Boost Technology 2.0 frequency |
4.7 GHz |
|
Intel® Transactional Synchronization Extensions |
Yes |
|
Intel® Total Memory Encryption |
Yes |
|
Intel® Control-flow Enforcement Technology (CET) |
Yes |
|
Intel® Platform Firmware Resilience Support |
No |
|
Intel® Trust Domain Extensions (Intel® TDX) |
No |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel® Active Management Technology (Intel® AMT) |
Yes |
|
Intel® OS Guard |
Yes |
|
Intel Software Guard Extensions (Intel SGX) |
No |
|
Intel 64 |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
|
Intel Turbo Boost Max Technology 3.0 |
Yes |
|
AVX-512 Fused Multiply-Add (FMA) units |
2 |
|
Intel® Boot Guard |
Yes |
|
Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
|
Intel® Volume Management Device (VMD) |
Yes |
|
Mode-based Execute Control (MBE) |
Yes |
|
Intel® vPro™ Platform Eligibility |
Yes |
|
Intel® One-Click Recovery |
Yes |
|
Intel® Remote Platform Erase (RPE) |
Yes |
|
Intel® Virtualization Technology with Redirect Protection (VT-rp) |
Yes |
|
Intel vPro® Enterprise Platform Eligibility |
Yes |
|
Intel® Threat Detection Technology (TDT) |
No |
|
Intel® Total Memory Encryption - Multi Key |
Yes |
|
Intel® QuickAssist Software Acceleration |
No |
|
Intel® QuickAssist Technology (QAT) |
0 default devices |
|
Intel® Dynamic Load Balancer (DLB) |
0 default devices |
|
Intel® Data Streaming Accelerator (DSA) |
1 default devices |
|
Intel® In-memory Analytics Accelerator (IAA) |
0 default devices |
|
Intel® Advanced Matrix Extensions (AMX) |
Yes |
|
Operational conditions |
|
Tcase |
75 °C |
|
DTS Max |
99 °C |
|
Technical details |
|
Package carrier |
E2B |
|
Launch date |
Q1'26 |
|
Status |
Launched |
|
Memory speed (max) |
6400 MHz |
|
Number of UPI links |
0 |
|
Weight & dimensions |
|
Processor package size |
77.5 x 56.5 mm |
|
Other features |
|
Maximum internal memory |
4 TB |
