Processor |
|
Processor family |
Intel Core Ultra 7 |
|
Processor cores |
24 |
|
Processor socket |
FCLGA1851 |
|
Package type |
Box |
|
Processor manufacturer |
Intel |
|
Processor model |
270K Plus |
|
Processor operating modes |
64-bit |
|
Processor generation |
Intel Core Ultra (Series 2) |
|
Processor threads |
24 |
|
Performance cores |
8 |
|
Efficient cores |
16 |
|
Low Power Efficient-cores |
0 |
|
Processor boost frequency |
5.5 GHz |
|
Performance-core boost frequency |
5.4 GHz |
|
Performance-core base frequency |
3.7 GHz |
|
Efficient-core boost frequency |
4.7 GHz |
|
Efficient-core base frequency |
3.2 GHz |
|
Processor cache |
36 MB |
|
Processor cache type |
Smart Cache |
|
Processor base power |
125 W |
|
Maximum turbo power |
250 W |
|
AI software frameworks supported by CPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
|
Maximum number of DMI lanes |
8 |
|
Processor codename |
Arrow Lake |
|
Processor ARK ID |
245692 |
|
Neural processor unit (NPU) |
|
Neural processor unit (NPU) |
Intel AI Boost |
|
Sparsity support |
Yes |
|
Windows Studio effects support |
Yes |
|
AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
|
Total processor performance up to |
36 TOPs |
|
NPU performance up to |
13 TOPs |
|
GPU performance up to |
8 TOPs |
|
Memory |
|
Memory channels |
Dual-channel |
|
Maximum internal memory supported by processor |
256 GB |
|
ECC |
Yes |
|
Graphics |
|
On-board graphics card |
Yes |
|
Discrete graphics card |
No |
|
On-board graphics card model |
Intel® Graphics |
|
Discrete graphics card model |
Not available |
|
On-board graphics card base frequency |
300 MHz |
|
On-board graphics card dynamic frequency (max) |
2000 MHz |
|
Number of displays supported (on-board graphics) |
4 |
|
On-board graphics card DirectX version |
12.0 |
|
On-board graphics card OpenGL version |
4.5 |
|
On-board graphics card maximum resolution (DisplayPort) |
7680 x 4320 pixels |
|
On-board graphics card refresh rate at maximum resolution (DisplayPort) |
60 Hz |
|
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) |
120 Hz |
|
On-board graphics card refresh rate at maximum resolution (HDMI) |
60 Hz |
|
On-board graphics card ID |
0x7D67 |
|
Hardware encode/decode codecs supported |
H.264, H.265 (HEVC) |
|
Xe-cores |
4 |
|
AI software frameworks supported by GPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebGPU |
|
AV1 encode/decode |
Yes |
|
Features |
|
Execute Disable Bit |
Yes |
|
Idle States |
Yes |
|
Thermal Monitoring Technologies |
Yes |
|
Market segment |
Desktop |
|
Use conditions |
Workstation, PC/Client/Tablet |
|
Maximum number of PCI Express lanes |
24 |
|
PCI Express slots version |
4.0, 5.0 |
|
Supported instruction sets |
AVX 2.0, SSE4.1, SSE4.2 |
|
Scalability |
1S |
|
Embedded options available |
No |
|
Thermal solution specification |
PCG 2020A |
|
Direct Media Interface (DMI) Revision |
4.0 |
|
Processor special features |
|
Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
|
Intel® Turbo Boost Technology |
2.0 |
|
Intel® Quick Sync Video Technology |
Yes |
|
Intel® AES New Instructions (Intel® AES-NI) |
Yes |
|
Enhanced Intel SpeedStep Technology |
Yes |
|
Intel Trusted Execution Technology |
Yes |
|
Intel® Speed Shift Technology |
Yes |
|
Intel® Turbo Boost Max Technology 3.0 frequency |
5.5 GHz |
|
Intel® Thunderbolt 4 |
Yes |
|
Intel® Control-flow Enforcement Technology (CET) |
Yes |
|
Intel® Thread Director |
Yes |
|
Intel VT-x with Extended Page Tables (EPT) |
Yes |
|
Intel® Secure Key |
Yes |
|
Intel® Active Management Technology (Intel® AMT) |
Yes |
|
Intel® OS Guard |
Yes |
|
Intel 64 |
Yes |
|
Intel Virtualization Technology (VT-x) |
Yes |
|
Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
|
Intel Turbo Boost Max Technology 3.0 |
Yes |
|
Intel® Boot Guard |
Yes |
|
Intel® Deep Learning Boost (Intel® DL Boost) on CPU |
Yes |
|
Intel® Volume Management Device (VMD) |
Yes |
|
Mode-based Execute Control (MBE) |
Yes |
|
Intel® vPro™ Platform Eligibility |
Yes |
|
Intel® Standard Manageability (ISM) |
Yes |
|
Intel® One-Click Recovery |
Yes |
|
Intel® Stable IT Platform Program (SIPP) |
Yes |
|
Intel® Remote Platform Erase (RPE) |
Yes |
|
Intel® Virtualization Technology with Redirect Protection (VT-rp) |
Yes |
|
Intel® Deep Learning Boost (Intel® DL Boost) on GPU |
Yes |
|
Intel vPro® Enterprise Platform Eligibility |
Yes |
|
Intel® Threat Detection Technology (TDT) |
Yes |
|
Intel® Total Memory Encryption - Multi Key |
Yes |
|
Intel vPro® Essentials Platform Eligibility |
Yes |
|
Operational conditions |
|
Maximum operating temperature |
105 °C |
|
Technical details |
|
OpenCL version |
3.0 |
|
Launch date |
Q1'26 |
|
Status |
Launched |
|
Weight & dimensions |
|
Processor package size |
45 x 37.5 mm |
|
Other features |
|
L2 cache |
40960 KB |
|
Maximum internal memory |
256 GB |
|
Graphics output |
eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL |
