General Information |
|
Summary |
The USB™ 3.0 Gigabit Ethernet Adapter gives you the ability to add a Gigabit Ethernet port to your laptop or MacBook® though a single USB™ 3.0 Type-A port, supporting 10/100/1000 Mbps Ethernet and is fully compatible with IEEE 802.3/az/u/ab/x standards.
This ethernet adapter provides full gigabit bandwidth and offers backward compatibility with USB™ 2.0. It also supports features such as IPv4/IPv6/TCP/UDP packet Checksum Offload Engine (COE) and TCP Large Send Offload to reduce the load on your CPU. Jumbo Frames, full-duplex operation, VLAN tagging and 2 VLAN ID filtering are also supported, making this an ideal replacement LAN adapter or laptop accessory in areas without Wi-Fi® or if you just want to increase your Internet speed. |
|
Ports & interfaces |
|
Connectivity technology |
Wired |
|
Host interface |
USB |
|
Network |
|
Ethernet LAN |
Yes |
|
Ethernet LAN (RJ-45) ports |
1 |
|
Ethernet LAN data rates |
10,100,1000 Mbit/s |
|
Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
|
Performance |
|
Product colour |
Silver, White |
|
Data transfer rate |
5 Gbit/s |
|
LED indicators |
Activity, Link |
|
Housing material |
Aluminium |
|
Country of origin |
Taiwan |
|
Compatibility |
Backwards compatible with USB™ 3.0, 2.0, and 1.1 hosts and devices, Instant connection to a wired network over USB™
Devices include:
Macbook™ Pro (Up to model year 2015)
Macbook™ Air (Up to model year 2017)
Surface Pro™ 7
Surfacebook™ |
|
Power |
|
Output voltage |
5 V |
|
Output current |
0.2 A |
|
Power consumption (typical) |
1 W |
|
Software |
|
Windows operating systems supported |
Yes |
|
Mac operating systems supported |
Yes |
|
Linux operating systems supported |
Yes |
|
Other operating systems supported |
ChromeOS |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 40 °C |
|
Storage temperature (T-T) |
-42 - 82 °C |
|
Weight & dimensions |
|
Width |
68 mm |
|
Depth |
14.5 mm |
|
Height |
23 mm |
|
Weight |
35 g |
|
Packaging data |
|
Quantity per pack |
1 pc(s) |
|
Package width |
120 mm |
|
Package depth |
97 mm |
|
Package height |
25 mm |
|
Package weight |
76.5 g |
|
Packaging content |
|
Quick start guide |
Yes |
|
Packaging content |
1 x JUE130 USB™ 3.0 Gigabit Ethernet Adapter, 1 x Quick Installation Guide, 1 x Driver Installation CD |
|
Batteries included |
No |
|
Technical details |
|
Master (outer) case GTIN (EAN/UPC) |
24712795080241 |
|
Warranty period |
2 year(s) |
|
Logistics data |
|
Products per master (outer) case |
20 pc(s) |
|
Master (outer) case width |
280 mm |
|
Master (outer) case length |
210 mm |
|
Master (outer) case height |
145 mm |
|
Master (outer) case gross weight |
2.17 kg |
|
Export Control Classification Number (ECCN) |
EAR99 |
|
Other features |
|
Cable length |
0.145 m |
|
Cable type |
USB 3.0 |
|
Maximum data transfer rate |
1000 Mbit/s |
|
Interface |
Ethernet |
|
Compatible operating systems |
Windows, Mac, Linux |
|
Contents |
1 x JUE130 USB™ 3.0 Gigabit Ethernet Adapter, 1 x Quick Installation Guide |
