Management features |
|
Switch type |
Managed |
|
Switch layer |
L2 |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
5 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
Gigabit Ethernet (copper) ports quantity |
5 |
|
Network |
|
Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
|
10G support |
No |
|
Copper ethernet cabling technology |
10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-T |
|
Port mirroring |
Yes |
|
Flow control support |
Yes |
|
Link aggregation |
Yes |
|
Broadcast storm control |
Yes |
|
Rate limiting |
Yes |
|
Auto MDI/MDI-X |
Yes |
|
Auto-negotiation |
Yes |
|
VLAN support |
Yes |
|
Data transmission |
|
MAC address table |
2000 entries |
|
Switching capacity |
10 Gbit/s |
|
Forwarding rate |
7.44 Mpps |
|
Store-and-forward |
Yes |
|
Number of queues |
4 |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
16000 |
|
Packet buffer memory |
1 MB |
|
Security |
|
IGMP snooping |
Yes |
|
Loop protection |
Yes |
|
Design |
|
Rack mounting |
No |
|
Product colour |
White |
|
LED indicators |
Status |
|
Performance |
|
Fanless |
Yes |
|
Power |
|
Power source |
DC |
|
Power supply included |
Yes |
|
DC input voltage |
12 - 57 V |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet plus (PoE+) ports quantity |
4 |
|
Power over Ethernet (PoE) power per port |
24 W |
|
Total Power over Ethernet (PoE) budget |
48 W |
|
Operational conditions |
|
Operating temperature (T-T) |
-40 - 60 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Storage relative humidity (H-H) |
10 - 95% |
|
Weight & dimensions |
|
Width |
150 mm |
|
Depth |
210 mm |
|
Height |
52 mm |
|
Weight |
750 g |
|
Packaging content |
|
User guide |
Yes |
|
Packaging data |
|
Package width |
286 mm |
|
Package depth |
466 mm |
|
Package height |
258 mm |
|
Package weight |
1.35 kg |
|
Certificates |
|
Certification |
FCC, CE, RoHS |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
