General Information |
|
Summary |
Are you looking for our most flexible and powerful tower server for your SMB and remote offices? The HPE ProLiant Compute ML350 Gen12 is a robust 2P tower server with optional rackable chassis for various environments, and delivers exceptional compute performance, security, reliability, and expandability. Powered by latest Intel Xeon 6700/6500 P-series processors (up to 86 P-cores per socket), up to 8 TB DDR5 6400 memory, the HPE ProLiant Compute ML350 Gen12 server fulfills a wide range of demanding workloads. The silicon root of trust anchors the server firmware to an HPE-exclusive ASIC, creating a fingerprint for the Intel Xeon 6700/6500 P-series processors that must be matched exactly before the server will boot. The HPE ProLiant Compute ML350 Gen12 server is an excellent choice for diverse workloads such as IT infrastructure, data management, VDI, and ERP/CRM. Scale and adapt to any environment with this server and accelerate your growing business.
What is new supporting point:
Supports ultra-high SSD performance with NVMe x4 and EDSFF drive cages, and allowing mixed dual-mode LFF and tri-mode SFF drive cages as hybrid storage optimization solution
Supports NVIDIA L4 24GB Accelerator.
Provides up to 24 NVMe drives with PCIe Gen5 x2 bandwidth to have maximum storage capacity with balanced performance solution
Includes HPE Integrated Lights-Out 7 (iLO 7) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Compute Gen12 servers seamlessly from anywhere
Supports new NS204i-u V2 as hot-pluggable, high-availability, RAID1-protected M.2 NVMe boot option
Powered by Intel Xeon 6700 and 6500 series with P-cores; up to 86 P-cores per socket (172 P-cores per server), 350W (TDP); increased memory bandwidth to 6400 MT/s[2], up to 8 TB DDR5 memory capacity |
|
Processor |
|
Processor cache type |
L3 |
|
Memory |
|
Internal memory type |
DDR5-SDRAM |
|
Storage |
|
Optical drive type |
No |
|
Supported RAID controllers |
Choice of storage controllers with OCP type (OROC) and standup form factor. Refer to the QuickSpecs for more detail. |
|
Design |
|
Chassis type |
Tower (4U) |
|
Performance |
|
Management platform |
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced, HPE OneView Advanced (require licenses), and HPE Compute Ops Management. Refer to the iLO 7 User Guide |
|
Trusted Platform Module (TPM) |
Yes |
|
Trusted Platform Module (TPM) version |
2.0 |
|
Power |
|
Power supply type |
1 or 2 Flexible Slot Power Supply |
|
Weight & dimensions |
|
Depth |
1000.1 mm |
|
Height |
333.4 mm |
|
Weight |
52.4 kg |
|
Other features |
|
Security features |
UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion Cable (Optional), Padlock slot and Kensington Lock slot support. For full security features refer to the QuickSpecs. |
|
Number of processors supported |
2 |
|
Dimensions (W x D x H) (imperial) |
600.2 x 1000 x 333.5 mm (23.6 x 39.4 x 13.1") |
|
Weight (imperial) |
52.4 kg (115.5 lbs) |
|
Ports & interfaces |
|
Expansion slots |
Up to 10[1] PCIe Gen5 and 2 OCP slots. Refer to the QuickSpecs for more detail. |
