StarTech 26-Foot OM3 Multimode Duplex Fibre Optic Cable LC/LC Aqua
|
|
Price: $46.00
Manufacturer:
StarTech
StarTech 8m (26ft) LC/UPC to LC/UPC OM3 Multimode Fiber Optic Cable, Full Duplex 50/125, 100G, LSZH Fiber Jumper Cord
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
60546909
|
A50FBLCLC8
|
65030928427 |
Active
|
Details
|
General Information |
|
Summary |
LSZH Jacket | Aramid Fiber Sheath | Ideal for SANs, data servers, SFP+
The A50FBLCLC8850nm Laser-Optimized Multimode Fiber (LOMMF) Aqua Cord features 50/125 micron fiber for high-speed, high bandwidth data transmissions over 10 Gigabit Ethernet and Fiber Channel networks - the perfect solution for fiber cable runs between multiple backbone switches, hubs and routers as well as higher end networking equipment.
This LC-LC patch cable is housed in a LSZH (Low-Smoke, Zero-Halogen) flame retardant jacket, to ensure minimal smoke, toxicity and corrosion when exposed to high sources of heat, in the event of a fire - an ideal solution for use in industrial settings, central offices and schools, as well as residential settings where building codes are a consideration.
Each Duplex 50/125 (OM3) Multimode Fiber Patch Cable is individually tested and certified to be within acceptable optical insertion loss limits for guaranteed compatibility and 100% reliability, and is backed by our lifetime warranty. |
|
Features |
|
Cable length |
8 m |
|
Connector 1 |
LC |
|
Connector 2 |
LC |
|
Connector 1 gender |
Male |
|
Connector 2 gender |
Male |
|
Product colour |
Aqua colour |
|
Jacket material |
Low smoke zero halogen (LSZH) |
|
Fibre optic type |
OM3 |
|
Cable shape |
Round |
|
Connector polish type |
UPC |
|
Full duplex |
Yes |
|
Core diameter |
50 µm |
|
Cladding diameter |
125 µm |
|
Fiber mode structure |
Multi-mode |
|
Wavelengths supported |
850,950,953,1050,1150,1250,1260,1280,1300 nm |
|
Data transfer rate |
100 Gbit/s |
|
Certificates |
|
Compliance certificates |
CE, RoHS |
|
Operational conditions |
|
Operating temperature (T-T) |
-20 - 60 °C |
|
Storage temperature (T-T) |
-20 - 60 °C |
|
Weight & dimensions |
|
Cable diameter |
2.9 mm |
|
Weight |
67 g |
|
Packaging data |
|
Package width |
220 mm |
|
Package depth |
200 mm |
|
Package height |
30 mm |
|
Package weight |
116 g |
|
Packaging content |
|
Quantity per pack |
1 pc(s) |
|
Logistics data |
|
Master (outer) case width |
410 mm |
|
Master (outer) case length |
410 mm |
|
Master (outer) case height |
450 mm |
|
Products per master (outer) case |
96 pc(s) |
|
