General Information |
|
Summary |
Outperforming the competition
The DGS-3630-28TC was benchmarked against a market leading competitor's device. It matched or exceeded the competitor's performance across all tests despite being significantly lower in price with a much lower power consumption.
Versatile Management
The DGS-3630 Series provides:
- Network Assistant Utility
- Industry-standard CLI
- Intuitive web-based management interface
Support for SNMP allows centralized management of a large number of devices and out-of-band management is available via a dedicated console port.
A mini-USB console port allows the DGS-3630 Series to be managed without any extra connectors, and a USB Type A port can be used to store logs, configuration, and firmware images.
High Availability and Flexibility
Includes stacking technology, which allows multiple switches to be combined to form a single physical or virtual stack.
Scale your network using just a stacking cable and without the need for stacking modules.
Increased redundancy over multiple physical units, simplifies management and provides a single IP address to manage all members in the stack.
Security, Performance & Availability
Robust set of QoS features helps ensure that critical network services such as Voice over IP and video conferencing are given high priority through the network.
The D-Link Safeguard Engine increases the switch’s reliability, serviceability, and availability by preventing malicious flooding traffic caused by worms or virus attacks. |
|
Management features |
|
Switch type |
Managed |
|
Switch layer |
L3 |
|
Quality of Service (QoS) support |
Yes |
|
Web-based management |
Yes |
|
Ports & interfaces |
|
Basic switching RJ-45 Ethernet ports quantity |
20 |
|
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
|
Installed SFP modules quantity |
0 |
|
Installed SFP+ modules quantity |
0 |
|
Combo SFP ports quantity |
4 |
|
SFP+ module slots quantity |
4 |
|
Fiber optic connector |
SFP+ |
|
Console port |
RJ-45/Mini-USB |
|
USB 2.0 ports quantity |
1 |
|
Network |
|
Networking standards |
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Qbb, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at |
|
10G support |
Yes |
|
Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
|
Port mirroring |
Yes |
|
Full duplex |
Yes |
|
IP routing |
Yes |
|
Routing entries |
16000 |
|
Flow control support |
Yes |
|
Link aggregation |
Yes |
|
Head-of-line (HOL) blocking |
Yes |
|
Auto-negotiation |
Yes |
|
Ethernet Ring Protection Switching (ERPS) |
Yes |
|
VLAN support |
Yes |
|
Virtual LAN features |
Private VLAN, Voice VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN |
|
Number of VLANs |
4000 |
|
Data transmission |
|
MAC address table |
68000 entries |
|
Switching capacity |
128 Gbit/s |
|
Forwarding rate |
95.24 Mpps |
|
Store-and-forward |
Yes |
|
Static route |
Yes |
|
Number of static routes |
512 |
|
Jumbo frames support |
Yes |
|
Jumbo frames |
12000 |
|
Packet buffer memory |
4 MB |
|
Security |
|
DHCP features |
DHCP server, DHCP client |
|
Access Control List (ACL) |
Yes |
|
IGMP snooping |
Yes |
|
Security algorithms |
802.1x RADIUS, SNMP, SNMPv3, SSH, SSL/TLS |
|
SSH/SSL support |
Yes |
|
Loop protection |
Yes |
|
BPDU filtering/protection |
Yes |
|
IP-MAC-Port binding |
Yes |
|
Multicast features |
|
Multicast support |
Yes |
|
Multicast Listener Discovery (MLD) snooping |
MLD v1, MLD v2 |
|
Design |
|
Rack mounting |
Yes |
|
Stackable |
Yes |
|
Product colour |
Black, Grey |
|
Number of fans |
4 fan(s) |
|
Safety |
cUL, CB, CE, CCC, BSMI |
|
Electromagnetic compatibility |
CE, FCC A, C-Tick, VCCI, BSMI, CCC |
|
Performance |
|
Physical stacking (units) |
9 |
|
Virtual stacking (units) |
32 |
|
Built-in processor |
Yes |
|
Power |
|
Redundant power supply (RPS) support |
Yes |
|
AC input voltage |
100 - 240 V |
|
AC input frequency |
50 - 60 Hz |
|
Power over Ethernet (PoE) |
|
Power over Ethernet (PoE) |
Yes |
|
Power over Ethernet plus (PoE+) ports quantity |
24 |
|
Power over Ethernet (PoE) power per port |
30 W |
|
Total Power over Ethernet (PoE) budget |
370 W |
|
Operational conditions |
|
Operating temperature (T-T) |
-5 - 50 °C |
|
Storage temperature (T-T) |
-40 - 70 °C |
|
Operating relative humidity (H-H) |
10 - 95% |
|
Storage relative humidity (H-H) |
5 - 95% |
|
Weight & dimensions |
|
Width |
441 mm |
|
Depth |
380 mm |
|
Height |
44 mm |
|
Weight |
5.88 kg |
|
Packaging data |
|
Package width |
538 mm |
|
Package depth |
560 mm |
|
Package height |
170 mm |
|
Package weight |
8.24 kg |
|
Technical details |
|
Shipping (inner) case height |
57.2 cm |
|
Shipping (inner) case width |
36.2 cm |
|
Shipping (inner) case length |
57.9 cm |
|
Shipping (inner) case net weight |
12.9 kg |
|
Products per shipping (inner) case |
2 pc(s) |
|
Pallet gross weight (air) |
342.4 kg |
|
Master (outer) cases per pallet (air) |
18 pc(s) |
|
Products per pallet (air) |
36 pc(s) |
|
Pallet gross length |
110 cm |
|
Pallet gross width |
120 cm |
|
Pallet height (air) |
185.1 cm |
|
Pallet gross weight (sea) |
342.4 kg |
|
Master (outer) cases per pallet (sea) |
18 pc(s) |
|
Products per pallet (sea) |
36 pc(s) |
|
Pallet height (sea) |
185.1 cm |
|
Shipping (inner) case gross weight |
18 kg |
|
Logistics data |
|
Harmonized System (HS) code |
85176990 |
