StarTech 7-Foot 12-Fiber MTP/PC OM4 Multimode Plenum Fiber Cable
|
|
Price: $189.00
Manufacturer:
StarTech
StarTech 2m (6ft) MTP®/MPO Fiber Optic Cable, 12F Type-B, OM4 Multimode MTP/PC Female Fiber Patch Cable, 50/125µm, OFNP Plenum, MTP-12 Fiber Jumper Cord
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
60551506
|
OM4MTP12BOFNP2M
|
65030930390 |
Active
|
Details
|
General Information |
|
Summary |
Safely route high-density MTP/MPO fiber cabling in plenum spaces
This OM4 MTP®/MPO multimode fiber cable supports high-density 40G and 100G connections between switches and servers, helping reduce cable bulk and simplify routing across data hall racks. The 12-fiber design supports high-speed MTP®/MPO connectivity for multi-fiber network applications, while the Erika Violet jacket follows TIA standards to clearly distinguish OM4 from Aqua OM3 cabling.
Engineered for Reliable Multimode Performance
Constructed with OM4 50/125µm laser-optimized Corning glass, this cable delivers consistent high-bandwidth transmission for data center and backbone links. Type-B polarity MTP® Elite connector maintains proper transmit/receive alignment for multi-lane connections, ensuring reliable performance without additional crossover components. Each cable is individually tested for signal integrity.
Plenum-Rated for In-Building Installation
The OFNP plenum-rated jacket meets strict fire and low-smoke requirements, making it suitable for routing through air-handling spaces in commercial and enterprise environments, including data center and in-wall pathways.
Deploy in Scalable Fiber Networks
Designed for use with structured MTP®/MPO systems, including multi-fiber trunks, cassettes, and patching setups, this cable supports scalability for growing fiber networks and straightforward migration between 10G, 40G, and 100G infrastructure. The 12-fiber format enables high-density connectivity while reducing overall cable count for cleaner, more efficient installations. |
|
Features |
|
Cable length |
2 m |
|
Connector 1 |
MPO/MTP |
|
Connector 2 |
MPO/MTP |
|
Connector 1 gender |
Male |
|
Connector 2 gender |
Male |
|
Product colour |
Violet |
|
Jacket material |
Optical fiber non-conductive plenum (OFNP) |
|
Fibre optic type |
OM4 |
|
Cable shape |
Round |
|
Connector polish type |
PC |
|
Core diameter |
50 µm |
|
Cladding diameter |
125 µm |
|
Fiber mode structure |
Multi-mode |
|
Data transfer rate |
100 Gbit/s |
|
Polarity |
B |
|
Certificates |
|
Compliance certificates |
RoHS, CE |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 70 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Weight & dimensions |
|
Cable diameter |
3 mm |
|
Weight |
26 g |
|
Packaging data |
|
Package width |
230 mm |
|
Package depth |
180 mm |
|
Package height |
15 mm |
|
Packaging content |
|
Quantity per pack |
1 pc(s) |
|
Logistics data |
|
Master (outer) case width |
420 mm |
|
Master (outer) case length |
420 mm |
|
Master (outer) case height |
270 mm |
|
Products per master (outer) case |
110 pc(s) |
|
