General Information |
|
Summary |
Connect a USB Type-C device to a USB-A wall charger or host computer
Charge a USB Type-C mobile device or transfer files to a USB-A host computer with this high-quality USB-A to Type-C cable. The USB-A to USB-C charger cord supports up to 15W and 3A output for fast charging. It supports USB 2.0 (480Mbps) transfer rates and is suitable for general use. Quick ID connectors with performance markings eliminate confusion, helping you identify the right cable instantly.
Rugged and Flexible
The USB-C Charging Cable features a TPE inner jacket with a braided nylon exterior for optimal flexibility and wear protection. The durable nickel-plated connectors are designed for frequent daily use, and are rated to operate beyond 10,000 insertion cycles.
Charge Mobile Devices
This durable USB-A to USB-C charging cord is Ideal for workstations in high-density setups or demanding environments. Facilitating up to 15W and 3A of output, the USB-C Charger Cord can fast-charge a smartphone or small tablet. To use, connect the cable from a USB-C device to a USB-A wall charger or hub. |
|
Features |
|
USB version |
USB 2.0 |
|
Connector 1 |
USB A |
|
Connector 2 |
USB C |
|
Connector 1 gender |
Male |
|
Connector 2 gender |
Male |
|
Product colour |
White |
|
Connector 1 form factor |
Straight |
|
Connector 2 form factor |
Straight |
|
AWG wire size |
28/21 |
|
Connector contacts plating |
Nickel |
|
Cable jacket material |
Thermoplastic elastomer (TPE), Nylon |
|
Cable jacket type |
Braided |
|
Maximum data transfer rate |
0.48 Gbit/s |
|
Cable type |
Round cable |
|
Plug and Play |
Yes |
|
USB Power Delivery (USB PD) |
Yes |
|
USB Power Delivery up to |
15 W |
|
Power |
|
Input current (max) |
3 A |
|
Weight & dimensions |
|
Cable length |
0.91 m |
|
Cable diameter |
4.5 mm |
|
Weight |
35 g |
|
Packaging data |
|
Package width |
140 mm |
|
Package depth |
130 mm |
|
Package height |
18 mm |
|
Package weight |
59.5 g |
|
Packaging content |
|
Quantity per pack |
1 pc(s) |
|
Operational conditions |
|
Operating temperature (T-T) |
-20 - 40 °C |
|
Storage temperature (T-T) |
-20 - 70 °C |
|
Certificates |
|
Compliance certificates |
CE |
|
Logistics data |
|
Products per master (outer) case |
80 pc(s) |
|
Master (outer) case width |
400 mm |
|
Master (outer) case length |
320 mm |
|
Master (outer) case height |
300 mm |
