General Information |
|
Summary |
Whatever the setting or resolution, lead your team to victory with elite gaming performance from a powerful 8‑core AMD gaming processor featuring AMD 3D V‑Cache™ technology.
|
|
Processor |
|
Processor family |
AMD Ryzen™ 7 |
|
Processor cores |
8 |
|
Processor socket |
Socket AM5 |
|
Processor lithography |
5 nm |
|
Package type |
Box |
|
Cooler included |
No |
|
Processor manufacturer |
AMD |
|
Processor model |
7700X3D |
|
Processor base frequency |
4 GHz |
|
Processor operating modes |
64-bit |
|
Processor generation |
AMD Ryzen 7000 Series |
|
Processor threads |
16 |
|
Processor boost frequency |
4.5 GHz |
|
Processor cache |
96 MB |
|
Processor cache type |
L3 |
|
Thermal Design Power (TDP) |
120 W |
|
Compatible chipsets |
AMD A620, AMD X670E, AMD X670, AMD B650, AMD B650E, AMD X870, AMD X870E, AMD B840, AMD B850 |
|
Memory |
|
Memory channels |
Dual-channel |
|
Maximum internal memory supported by processor |
128 GB |
|
Memory types supported by processor |
DDR5-SDRAM |
|
Memory clock speeds supported by processor |
5200,3600 MHz |
|
ECC |
Yes |
|
Graphics |
|
On-board graphics card |
Yes |
|
Discrete graphics card |
No |
|
On-board graphics card model |
AMD Radeon Graphics |
|
Discrete graphics card model |
Not available |
|
On-board graphics card base frequency |
2200 MHz |
|
Features |
|
PCI Express slots version |
5.0 |
|
Processing Die size |
71 mm² |
|
Compatible operating systems |
Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
|
Operational conditions |
|
Minimum operating temperature |
89 °C |
