General Information |
|
Summary |
550VA 330W GREEN 8OUT 5-15R USB RJ11 MGMT SOFT 3YR |
|
Features |
|
UPS topology |
Standby (Offline) |
|
Output power capacity |
0.55 kVA |
|
Output power |
330 W |
|
Input frequency |
50/60 Hz |
|
Surge energy rating |
890 J |
|
Audible alarm(s) |
Yes |
|
Ports & interfaces |
|
AC outlet types |
NEMA 5–15R |
|
AC outlets quantity |
8 AC outlet(s) |
|
USB 2.0 ports quantity |
1 |
|
Serial ports quantity |
0 |
|
Modem (RJ-11) ports |
1 |
|
Ethernet LAN (RJ-45) ports |
0 |
|
Battery |
|
Battery technology |
Sealed Lead Acid (VRLA) |
|
Typical backup time at full load |
2 min |
|
Typical backup time at half load |
8 min |
|
Battery recharge time |
8 h |
|
Hot-swap battery |
No |
|
Design |
|
Form factor |
Compact |
|
Product colour |
Black |
|
Cable length |
1.52 m |
|
LED indicators |
Yes |
|
Operational conditions |
|
Operating temperature (T-T) |
0 - 35 °C |
|
Operating relative humidity (H-H) |
0 - 90% |
|
Certificates |
|
Compliance certificates |
RoHS |
|
Certification |
UL1778, cUL 107.3, FCC DOC Class B |
|
Other features |
|
Battery type |
12V/5.5AH |
|
Nominal output voltage |
110-120 V |
|
Nominal input voltage |
96-140 V |
|
Weight (imperial) |
2.9 kg (6.4 lbs) |
|
Dimensions (W x D x H) (imperial) |
247.7 x 76.2 x 152.4 mm (9.75 x 3 x 6") |
