APC Rack PDU Basic Zero U 14.4kW 208V
|
|
Regularly: $1590.00
On Sale: $1526.40
Sale Ends:
April 26th, 2024
Manufacturer:
APC
Rack PDU,Basic, Zero U,14.4kW,208V,(24)C13,(4)C19,(2)L6-30R;3' Cord
|
|
Availability
|
Ottawa Store: Inquire Online Here
National Warehouse (Shipping Availability):
Usually Ships in 24-48 Hours
|
|
|
|
| Product # |
Manufacturer # |
UPC # |
Status |
|
93426
|
AP7569
|
- |
Active
|
Details
|
General Information |
|
Summary |
Toolless Mounting Capabilities
Units do not require additional tools to mount into APC NetShelter Enclosure, which allows the users to quickly and easily mount units in the rear of the enclosure.
Vertical Mounting Capabilities
Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures.
Resettable circuit breakers
Enables a quick recovery from overload events. |
|
Design |
|
Product colour |
Black |
|
Ports & interfaces |
|
Input connection type |
CS8365 |
|
Output connections |
24x IEC 320 C13
4x IEC 320 C19
2x NEMA L6-30R |
|
Features |
|
Cable length |
0.91 m |
|
Certification |
cUL Listed,CSA,METI Denan,UL 60950,UL Listed |
|
Power |
|
Nominal input voltage |
208 V |
|
Nominal output voltage |
208 V |
|
Load capacity |
14400 VA |
|
Maximum input current per phase |
50 A |
|
Weight & dimensions |
|
Dimensions (WxDxH) |
55 x 95 x 1778 mm |
|
Weight |
7.32 kg |
|
Operational conditions |
|
Operating temperature (T-T) |
-5 - 45 °C |
|
Storage temperature (T-T) |
-25 - 65 °C |
|
Operating relative humidity (H-H) |
5 - 95% |
|
Storage relative humidity (H-H) |
5 - 95% |
|
