Scanning |
|
Maximum scan size |
108 x 228 mm |
|
Optical scanning resolution |
300 x 300 DPI |
|
Duplex scanning |
Yes |
|
Colour scanning |
Yes |
|
Output colour depth |
24 bit |
|
Greyscale levels |
256 |
|
Design |
|
Built-in display |
No |
|
Product colour |
Black, Grey |
|
Performance |
|
Sensor type |
CMOS CIS |
|
Daily duty cycle (max) |
3000 pages |
|
Light source |
RGB LED |
|
Input capacity |
|
Auto document feeder (ADF) input capacity |
50 sheets |
|
Paper handling |
|
Long-paper mode |
Yes |
|
Media thickness (min) |
0.08 mm |
|
Card thickness (max) |
0.2 mm |
|
Auto Document Feeder (ADF) media weight |
64 - 157 g/m² |
|
Ports & interfaces |
|
USB port |
Yes |
|
USB version |
2.0 |
|
Standard interfaces |
USB 2.0 |
|
Power |
|
Power consumption (typical) |
15.8 W |
|
AC input frequency |
50 - 60 Hz |
|
Input voltage |
220-240 V |
|
Power consumption (sleep) |
2.3 W |
|
System requirements |
|
Windows operating systems supported |
Windows 10, Windows 7, Windows 8.1 |
|
Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
|
Operational conditions |
|
Operating temperature (T-T) |
10 - 32.5 °C |
|
Operating relative humidity (H-H) |
20 - 80% |
|
Weight & dimensions |
|
Width |
140 mm |
|
Depth |
223 mm |
|
Height |
188 mm |
|
Weight |
2.1 kg |
|
Packaging content |
|
Bundled software |
Ranger driver + IQA, Canon Scanning Utility |
